Wall Cabinets
D14
Wall Open Cabinets
Caution
! Installation of a wall cabinet 30” or wider requires additional support, such as attachment to
a soffit, or support from below.
Wall Open
Cabinets
Construction Options and
Modifications
I
Available with exceptions
l
Available with an upcharge
v
Included as standard
(Blank)
Not
Available
Installation notes
: Installation of a wall cabinet 30”
or wider, by itself, is
not
recommended and requires
additional support, such as attachment to a soffit or
support from below.
Material dimensions may vary slightly based on
lumber industry standards.
Specifications subject to change without notice.
PE Plywood Ends
APC All Plywood Construction
RD9 Reduce Depth 9”
ID15 Increase Depth 15”
ID18 Increase Depth 18”
ID21 Increase Depth 21”
ID24 Increase Depth 24”
WOC 15
30
code
width
height
Wall Open Cabinet
No shelf
12” High
WOC3012
WOC3612
One shelf
23 1/2” H
WOC1524
WOC1824
WOC2124
WOC2424
Two shelves
30” High
WOC1530
WOC1830
WOC2130
WOC2430
Three shelves
36” High
WOC1536
WOC1836
WOC2136
WOC2436
39” High
WOC1539
WOC1839
WOC2139
WOC2439
42” High
WOC1542
WOC1842
WOC2142
WOC2442
48” High
WOC1848
WOC2148
WOC2448
Three adjustable shelves,
one fixed shelf
54” High
WOC1854
WOC2154
WOC2454
60” High
WOC1860
WOC2160
WOC2460
• Adjustable shelves
• No door
• Matching laminate interior and
shelves
• Includes low profile clear
polycarbonate shelf supports in addition to
hold-down style supports used for shipping
• 54” and 60” high are designed for countertop
mount
Additional support is required. Wall
hung applications
must
be limited to
15 lbs. per square foot of shelf area;
not
to exceed 50 lbs. per shelf.
v
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
12˝
23 1/ ˝
30˝
36˝
39˝
42˝
48˝
54˝
60˝
12˝
Shown with two
adjustable shelves
Shown with three
adjustable shelves,
one fixed shelf
12˝
18˝
