12"
8 / ˝
8 / ˝
12"
143°
63½°
11 / ˝
30˝
36˝
39˝
42˝
Wall Cabinets
D13
Wall End Run Cabinets
Wall End Run
Cabinets
Construction Options and
Modifications
I
Available with exceptions
l
Available with an upcharge
v
Included as standard
(Blank)
Not
Available
Material dimensions may vary slightly based on
lumber industry standards.
Specifications subject to change without notice.
PE Plywood Ends
APC All Plywood Construction
BIS Bistro Glass
MD Traditional Mullion Glass
SV Savannah Mullion Glass
MI Matching Interior
CFO Cabinet Front Only
WCA 12
30
code
width
height
Wall Corner Angle
Specify R or L
Two shelves
WCA1230 R or L
Three shelves
WCA1236 R or L
WCA1239 R or L
WCA1242 R or L
• Adjustable shelves
• For use at end of cabinet run or in a corner
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
PE
l
APC
I
BIS
I
MD
I
SV
I
MI
l
CFO
12˝
12˝
45°
30˝
36˝
39˝
42˝
12˝
12˝
Wall End Corner
• Adjustable shelves
• Two doors
• Can be installed on either right or left end
of run or in a corner
PE
l
APC
BIS
MD
SV
MI
l
CFO
Solid Wood Wall End Open Shelf
Three shelves
SWEOS30
Four shelves
SWEOS36
SWEOS42
• 5/8” thick solid wood fixed shelves and top
• 30” high has three shelves with equal
spacing of 9 1/8” high
• 36” high has four shelves with equal
spacing of 8 3/16” high
• 42” high has four shelves with equal spacing of
9 11/16” high
• Invertible for right or left hand use
• Trimmable to 5 7/8” wide
• Back
not
finished
• End and back panels are 3/16” with veneered plywood
finish on exposed surfaces
PE
APC
BIS
MD
SV
MI
CFO
30˝
36˝
42˝
6 / ˝
12 ˝
6 / ˝
5 ³/ ˝
12 ˝
Two shelves
WEC1230
Three shelves
WEC1236
WEC1239
WEC1242
