Wall Cabinets
D21
Wall Specialty Cabinets
Door Storage
Specify R or L
DOS18 R or L
DOS24 BUTT
• Provides countertop out-of-sight storage for small
appliances
• Designed to be flush mounted with 12” deep wall
cabinets
• Frame and end panels oversized for custom fit
• End panels are shipped unattached
• “No back” design allows easy access to electrical outlets
and notching for backsplash
l
PE
l
APC
18 / ˝
18 / ˝
12˝
12˝
DOS18
DOS24 BUTT
Wall Filler Pull-out
WFP3.30
2 3/4” shelf width; 1 3/4” usable space
between chrome rails; 3 1/16” required
between adjacent cabinets
WFP6.30
5 3/4” shelf width; 4 3/4” usable space
between chrome rails; 6 1/16” required
between adjacent cabinets
• Three adjustable natural finished hardwood shelves
• 3/4” thick solid wood pre-drilled filler included, shipped
unattached
• Wood filler aligns with face frames of adjacent wall
cabinets
• Unit slides on full extension runners; one on the top and
two at the bottom
Must
be installed between two cabinets that are at least
30” high and 12” deep
• Natural finish hardwood interior
Do
not
use filler pullouts at the end of cabinet
runs or next to appliances. They
must
be
installed between two cabinets or a cabinet
and an end panel
PE
APC
30˝
12˝
3˝, 6˝
