Wall Cabinets
D19
Wall Hoods
Wall Hood Blower
WHB36•620
• 620 CFM/7.5 Sones; three-speed motor with push
button electronic control
• For installations with exterior ductwork
• Constructed of heavy gauge steel
• Pre-wired for electrical connection
• AC 120 volt required
• 8” diameter duct vents on top
• Dual bulb halogen lighting (PAR 20) included
• UL and HVI approved
• For use with Wall Hood Classic Chimney (WHCC)
• For use with Wall Hood Liner (WHL)
• Metallic medium gray painted finish on cover plate is
corrosion and rust resistant. Blowerbox has galvanized
finish
APC
8"
diameter
10 ½˝
11 ½˝
17 / ˝
12"
21 / ˝
Wall Hood Liner
WHL36
• Constructed of heavy gauge steel
• For installations with exterior ductwork
• For use with Wall Hood Cove (WHCV) and Wall Hood
Classic Chimney (WHCC)
• For use with Wall Hood Blower (WHB)
• Metallic medium gray painted finish
APC
34 / ˝
18 / ˝
4˝
11 ¼˝
17 / ˝
