Wall Cabinets
D17
Wall Microwave Cabinets
Caution
: Additional support is required.
Wall Microwave Shelf Cabinet
30” High
WMSC271230 (Butt)
36” High
WMSC241236 (Butt)
WMSC271236 (Butt)
42” High
WMSC271242 (Butt)
• 3/4” thick shelf extends 6 25/32” beyond
face frame
• No shelf in upper section
• Shelf shipped unattached for easier installation;
mounting hardware included
• Matching laminate interior
• Designed for countertop style microwaves
•
Note
:
Must
be installed between two cabinets or
between cabinet and side wall
l
PE
l
APC
ID21
ID24
l
CFO
Opening Sizes
Cabinet
WMSC241236
WMSC271230
WMSC271236
18 ³/ ˝ high x 21˝ wide x 18˝ deep (shelf)
15 ³/ ˝ high x 24˝ wide x 18˝ deep (shelf)
18 ³/ ˝ high x 24˝ wide x 18˝ deep (shelf)
21 ³/ ˝ high x 24˝ wide x 18˝ deep (shelf)
WMSC271242
12˝
18˝
30˝
36˝
42˝
12˝
15˝
18˝
Wall Microwave Shelf
12” Deep
WMS271218
WMS301218
15” Deep
WMS271518
WMS301518
• Shelf extends 3 25/32” beyond face frame
of cabinet
• Shelf shipped unattached for easier
installation; mounting hardware included
• Matching laminate interior
• Designed for countertop style microwaves
•
Note
:
Must
be installed between two cabinets or
between cabinet and side wall
l
PE
l
APC
ID21
ID24
CFO
Opening Sizes
Cabinet
WMS271218
WMS301218
WMS271518
24˝ wide x14 1/ ˝ high x 15˝ deep
27˝ wide x14 1/ ˝ high x 15˝ deep
24˝ wide x14 1/ ˝ high x 18˝ deep
27˝ wide x14 1/ ˝ high x 18˝ deep
WMS301518
12˝, 15˝
18˝
