Wall Cabinets
D16
Wall Microwave Cabinets
Caution
: Additional support is required.
Wall Microwave
Cabinets
Construction Options and
Modifications
I
Available with exceptions
l
Available with an upcharge
v
Included as standard
(Blank)
Not
Available
Installation note
s: Installation of a wall cabinet 30”
or wider, by itself, is
not
recommended and requires
additional support, such as attachment to a soffit or
support from below.
Any wall cabinet over 24” wide or 30” high with
a depth greater than 12” or butt doors
must
be
installed between two cabinets, a cabinet and a wall,
or supported from below.
Material dimensions may vary slightly based on
lumber industry standards.
Specifications subject to change without notice.
PE Plywood Ends
APC All Plywood Construction
ID21 Increase Depth 21”
ID24 Increase Depth 24”
CFO Cabinet Front Only
WMC 30 18 36
code
width
depth
height
Wall Microwave Cabinet 36” H
WMC271836 (Butt)
WMC301836 BUTT
• No shelf in upper section
• Matching laminate interior
• 4 1/2” wide trimmable face frame stiles
• Doors are attached with face-mounted
concealed hinges
• Designed for “built-in” style microwaves
•
Note
:
Must
be installed between two cabinets or
between cabinet and side wall
Installation of a wall cabinet 30” or wider, by
itself, is
not
recommended and requires
additional support, such as attachment to a
soffit or support from below
Remember, a cabinet designated BUTT or
(Butt) has no center stile. When you see the
word BUTT in all capitals, it
must
be included
as part of your ordering nomenclature, a (Butt) in
parentheses is for your information and isn’t required
on an order form.
l
PE
l
APC
l
ID21
l
ID24
l
CFO
Cabinet
Opening Size
Trimmable to
WMC271836
WMC301836
13˝ high x 18˝ wide
13˝ high x 21˝ wide
19 ½˝ high x 24˝ wide
19 ½˝ high x 27˝ wide
15˝
36˝
18˝
Wall Microwave Cabinet 45” H
WMC271845 (Butt)
WMC301845 BUTT
• No shelf in upper section
• Matching laminate interior
• 4 1/2” wide trimmable face frame stiles
• Doors are attached with face-mounted concealed
hinges
• Designed for “built-in” style microwaves
•
Note
:
Must
be installed between two cabinets or
between cabinet and side wall
l
PE
l
APC
l
ID21
l
ID24
l
CFO
Cabinet
Opening Size
Trimmable to
WMC271845
WMC301845
13½˝ high x 18˝ wide
13½˝ high x 21˝ wide
20˝ high x 24˝ wide
20˝ high x 27˝ wide
23 ½˝
45˝
18˝
