Wall Cabinets
D20
Wall Specialty Cabinets
Wall Specialty
Cabinets
Construction Options and
Modifications
I
Available with exceptions
l
Available with an upcharge
v
Included as standard
(Blank) Not Available
Material dimensions may vary slightly based on
lumber industry standards.
Specifications subject to change without notice.
PE Plywood Ends
APC All Plywood Construction
TSA 24
18
code
width
height
Tambour Storage
TS18
TS24
TS30
• Provides countertop out-of-sight storage for small appliances
• Designed to set back 1/4” from wall cabinet frame for easier
installation
• Fits under 18”, 24”, and 30” wide wall cabinets
• Features a torsion spring activated roll-up tambour door
• “No back” design allows easy access to electrical outlets and
notching for backsplash
• Bottom edges may be trimmed a maximum of 1” before
interfering with tambour track stop. Width
cannot
be trimmed
• End panels are 1/2” thick and have matching exterior surface.
End panels shipped unattached
• Matching laminate interior
• Holes for knobs are pre-drilled. One antique brass knob is
included with TS18 and TS24; two with TS30
• Installation instructions and mounting hardware included
PE
APC
18 ¼˝
Tambour Storage Angle
TSA2418
TSA2718
• Provides countertop out-of-sight storage for small appliances
• Designed to set back 1/4” from wall angle cabinet
frame for easier installation
• TSA24 for use under Wall Angle (WA24); TSA27 for
use under Wall Angle (WA27)
• Features a torsion spring activated roll-up tambour door
• “No back” design allows easy access to electrical outlets and
notching for backsplash
• Bottom edges may be trimmed a maximum of 1” before
interfering with tambour track stop
• End panels are 1/2” thick and have matching exterior surface.
End panels shipped unattached
• Matching laminate interior
• Hole for knob is pre-drilled and one antique brass knob included
• Installation instructions and mounting hardware included
•
Installation Note
: Requires field fabricated back on one side
when used with PWA
PE
APC
18 ¼˝
Spice Drawer Cabinet
SDC18
3 drawers
SDC24
4 drawers
SDC30
5 drawers
SDC36
6 drawers
• Solid half blind, 1/2” thick, dovetail drawers
• Drawer fronts are solid wood
• Matching wood veneer interior and exterior surfaces
• Includes a matching solid wood strip at each end to align with
cabinet when installed horizontally
• Interior drawer is 10” deep, 4 1/8” wide and 4 7/16” tall
• Units may be stacked horizontally or mounted vertically
• Decorative hardware may be required
PE
APC
6˝
12˝
Reveals
5½˝
5½˝ 5½˝
½˝
/ ˝ / ˝
¼˝
¼˝
SDC30
