Wall Cabinets
D4
Wall Cabinets
Caution
! Installation of a wall cabinet 30˝ or wider requires additional support,
such as attachment to a soffit, or support from below.
Wall Double Door 27” H
W3027 BUTT
W3327 BUTT
W3627 BUTT
W3927
W4227
• One adjustable shelf
• Any wall cabinet over 24˝ wide or 30˝
high with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
BIS
MD
SV
MI
l
CFO
12˝
27˝
Wall Refrigerator 24” Deep 27” H
WR3627 BUTT
WR3927
• One adjustable shelf
• Designed for use over refrigerators where
there is adequate clearance
• Additional support required
When designing a built-in
refrigerator area, remember that
many side by side refrigerators
measure up to 36” wide. If you have the
extra space, it is recommended to use at
least a 1” filler with a 36” wide Wall Refrigerator (WR)
cabinet to assure clearance for the appliance. Also,
verify the height of the appliance to make sure you are
using the correct Wall Refrigerator cabinet.
l
PE
l
APC
RD9
ID15
ID18
ID21
ID24
BIS
MD
SV
MI
l
CFO
27˝
24˝
Wall Single Door 30” H
Specify R or L
n
W930 R or L
n
W1230 R or L
W1530 R or L
W1830 R or L
W2130 R or L
W2430 R or L
• Two adjustable shelves
• Any wall cabinet over 24˝ wide or 30˝
high with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
30˝
12˝
n
Not
available with glass options (BIS, DRS.
PREP, MD, MD.PREP, SV, SV.PREP)
Wall Double Door 30” H
n
W2430 BUTT
W2730 (Butt)
n
W3030 BUTT
n
W3330 BUTT
n
W3630 BUTT
W3930
W4230
W4530
W4830
• Two adjustable shelves
• Any wall cabinet over 24˝ wide or 30˝
high with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
30˝
12˝
n
Available with glass options (BIS, DRS.PREP,
MD, MD.PREP, SV, SV.PREP)
