Specifications and Options
C8
Construction Options
Matching Interior
MI
• Matching interior option affects:
• End Panels
• Shelves
• Floors and Ceilings
• Back Panel
• Interior surfaces are easy clean laminate
I
Note:
Matching Interior (MI) option is
only
available in cabinets with Glass Door
(BIS_, MD_, SV_) or Prepared for Glass
Door (DRS.PREP_, MD.PREP_, SV.PREP_)
options
•
Note:
Matching Interior (MI)
must
be ordered with all glass doors
• Consult Matching Interior (MI) option box for availability for your
desired cabinet
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
I
MI
CFO
End
Panel
Matching
Interior
Solid hardwood face frame
Depth Modification
• Some cabinets can be reduced or
increased in depth to fit design
requirements. See specific cabinet
information for availability
• When this option is selected, Cabinet
Front Only (CFO) is no longer available
• Select trays are
not
available with this
option. See individual cabinets for specific
availability
• Cabinets that normally have drawers
ordered less than 18” deep will be replaced
with a false front only
• When base cabinets are reduced, shelf will
be 10 19/32” deep; shelves 39” wide and
wider will have a front cleat for additional
support, except Base Combination Drawer (BCD) cabinets
Note
: Additional support is required for wall cabinets
increased to 15” deep or deeper
PE
APC
l
RD9
l
RD12
l
RD15
l
RD18
l
RD21
l
ID15
l
ID18
l
ID21
l
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
Cabinet Front Only
CFO
• Front frame and appropriate doors and
drawer fronts only
• Does
not
include toe kick
•
Note
:
Cannot
be combined with any depth
modifications or tray options
We recommend using this option
on cabinetry containing no
factory installed accessories,
since all cabinet components will be
eliminated except face frame, doors and
drawer fonts. For example, order BCFS36L-CFO instead of LS36L-CFO
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
l
CFO
Deluxe Recessed Panel Drawer Front
DRPD
• 5-piece drawer front (DRPD) option is
only available in Paxton and Ridley door
styles; comes standard in Bellamy door
style
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
DRPD
Reduced Depth
RD9
RD12
RD15
RD18
RD21
Increased Depth
ID15
ID18
ID21
ID24
