Specifications and Options
C7
Construction Options
Construction
Options
Construction Options and
Modifications
I
- - Available with exceptions
l
- - Available with an upcharge
v
- - Included as standard
(Blank)
Not
Available
Use the option availability chart at the right of each
item to determine which construction options are
available for your desired cabinet.
Material dimensions may vary slightly based on
lumber industry standards.
Specification subject to change without notice.
PE - - - - Plywood Ends
APC - - - All Plywood Construction
RD9 - - - Reduce Depth 9”
RD12 - - - Reduce Depth 12”
RD15 - - - Reduce Depth 15”
RD18 - - - Reduce Depth 18”
RD21 - - - Reduce Depth 21”
ID15 - - - Increase Depth 15”
ID18 - - - Increase Depth 18”
ID21 - - - Increase Depth 21”
ID24 - - - Increase Depth 24”
BIS - - - - Bistro Glass
MD - - - - Traditional Mullion Glass
SV - - - - Savannah Mullion Glass
1ROT - - - 1 Roll-out Tray
2ROT - - - 2 Roll-out Trays
3ROT - - - 3 Roll-out Trays
4ROT - - - 4 Roll-out Trays
6ROT - - - 6 Roll-out Trays
1FWROT - - 1 Full Width Tray
2FWROT - - 2 Full Width Trays
2DROT - - 2 Deep Roll-out Trays
4DROT - - 4 Deep Roll-out Trays
6DROT - - 6 Deep Roll-out Trays
2DFWROT - 2 Deep Full Width Roll-out Trays
MI - - - - Matching Interior
CFO - - - Cabinet Front Only
Plywood Ends – PE
• This construction option affects end panels only
• Available for full or partial kitchen orders
• To order a full kitchen with Plywood Ends, use PE in the header of your order
• To order individual line items with Plywood Ends, dash each line item with PEB;
Order Example: W3030 BUTT-PEB
• 1/2” plywood end panels are available for most cabinets and have a wood veneer exterior and
woodgrain laminate interior
• Consult the Plywood Ends (PE) option box for your desired cabinet
• Shelves, ceilings and floors are engineered wood, finished with a natural woodgrain laminate
• Plywood End Panels do
not
receive glaze detailing
•
Note
: Standard Construction will be produced for product not identified as available with PE when ordered
under PE construction
l
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
PE
Full Kitchens
PEB
Individual Cabinets
Natural woodgrain
laminate
Wall, Base, Tall and Vanity
Solid hardwood face frame
Plywood
Stained or
painted veneer
to match door
and frame
¾˝
½˝
All Plywood Construction – APC
APC
Full Kitchens
AP
Individual Cabinets
• This construction option affects the entire cabinet
• Available for full or partial kitchen orders
• To order a full kitchen with All Plywood Construction use APC in the header of your order
• To order individual line items with All Plywood Construction, dash each line item with AP;
Order Example: W3030 BUTT-AP, B12L-AP
• All Plywood Construction (APC) is available for most cabinets
• Consult All Plywood Construction (APC) option box for your desired cabinet
• This All Plywood Construction option features:
• 1/2” plywood base, vanity and tall end panels
• 1/2” plywood wall and tall floors and ceilings, corner gussets and toe kick backer
• 1/2” plywood base and vanity floors
• 3/8” plywood wall backs
• 1/4” plywood base and vanity backs
• 1/4” plywood tall backs except for PC and U36 which is 3/8” plywood
• 5.2 mm plywood drawer bottoms
• 11/16” plywood wall, tall, base and vanity shelves
• 3/8” plywood wall hang rails
• Plywood End Panels do
not
receive glaze detailing
•
Note
: Standard construction will be produced for product
not
identified as available with APC when ordered under APC
construction
PE
l
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
Natural woodgrain
laminate
Wall, Base, Tall and Vanity
Solid hardwood face frame
Plywood
Stained or
painted veneer
to match door
and frame
¾˝
½˝
