Specifications and Options
C11
Construction Options
6 Roll-out Trays
6ROT
• Sides and back are 1/2” thick engineered wood
with 1/4” thick engineered wood bottom. Fronts
are 3/4” thick solid hardwood
• Available for most three door Base cabinets with
center stile
• Natural woodgrain laminate
• Shelves are omitted from cabinets when ROT
options are selected
• 3/4 extension side mount glide
• 75 lbs. capacity
• All Plywood Construction (APC) have solid wood
roll-out trays
•
Note
:
Not
available on cabinets reduced to 12” or 15” deep
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
l
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
1 Full-Width Tray
1FWROT
• Full-width standard tray spans the full width of
cabinet
• Sides and back are 1/2” thick engineered wood
with 1/4” thick engineered wood bottom. Fronts
are 3/4” thick solid hardwood
• Available for most Base and Universal Butt Door
cabinets
• Natural woodgrain laminate
• Shelves are omitted from cabinets when ROT
options are selected
• Trays 30” and wider will have a 3/8” thick
engineered wood bottom for additional support
• 3/4 extension side mount glide
• 75 lbs. capacity
• All Plywood Construction (APC) have solid wood roll-out trays
•
Note
:
Not
available on cabinets reduced to 12” or 15” deep
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
l
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
2 Full-Width Trays
2FWROT
• Full-width standard tray spans the full width of
cabinet
• Sides and back are 1/2” thick engineered wood
with 1/4” thick engineered wood bottom. Fronts
are 3/4” thick solid hardwood
• Available for most Base and Universal Butt Door
cabinets
• Natural woodgrain laminate
• Shelves are omitted from cabinets when ROT
options are selected
• Trays 30” wide and wider have a 3/8” thick
engineered wood bottom for additional support
• 3/4 extension side mount glide
• 75 lbs. capacity
• All Plywood Construction (APC) have solid wood roll-out trays
•
Note
:
Not
available on cabinets reduced to 12” or 15” deep
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
l
2FWROT
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
2 Deep Roll-out Trays
2DROT
• Sides, front and back, are 1/2” thick solid hardwood
with 3-ply 5.2mm thick plywood bottom panel
• 1 15/16” deep scalloped finger pull cut out
• Available for most Base and Universal cabinets
• Natural finish
• Shelves are omitted from cabinets when ROT
options are selected
• 3/4 extension side mount glide
• 75 lbs. capacity
• All Plywood Construction (APC) have solid wood
roll-out trays
•
Note
: Only available in 24” deep cabinets
PE
APC
RD9
RD12
RD15
RD18
RD21
ID15
ID18
ID21
ID24
BIS
MD
SV
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
l
2DROT
4DROT
6DROT
2DFWROT
MI
CFO
