A class used to add a background and a border to its content. This view supports clipping the content to the area defined by the border.
View Template Specification
| Type | Labels | Property | Description |
| Comment | background-color | Optional | The color of the background. Must be provided as a string in hexadecimal #RRGGBB or #RRGGBBAA format. Defaults to #00000000 (transparent). |
| Comment | border-thickness | Optional | The border thickness. Defaults to 0.0 (no border). |
| Comment | border-color | Optional | The color of the border. Must be provided as a string in hexadecimal #RRGGBB or #RRGGBBAA format. Defaults to #000000ff (black). |
| Comment | corner-radius | Optional | The radius of the corners of the view. This affects the visual representation of the background and border. Defauts to 0.0 (square corners). |
| Comment | corner-radius-top-left | Optional | The radius of the top-left corner on the view. This affects the visual representation of the background and border. Defaults to 0.0 (square corner). |
| Comment | corner-radius-top-right | Optional | The radius of the top-right corner on the view. This affects the visual representation of the background and border. Defaults to 0.0 (square corner). |
| Comment | corner-radius-bottom-left | Optional | The radius of the bottom-left corner on the view. This affects the visual representation of the background and border. Defaults to 0.0 (square corner). |
| Comment | corner-radius-bottom-right | Optional | The radius of the bottom-right corner on the view. This affects the visual representation of the background and border. Defaults to 0.0 (square corner). |
| Comment | overflow | Optional | The masking behaviour of the view in relation to content that overflows outside of the bounds of the view. Valid values: visible, hidden. Defaults to visible. |
|
| | CYIDecoratedView () |
| |
| virtual | ~CYIDecoratedView () |
| |
| virtual bool | Init () override |
| |
| void | SetBackgroundColor (const CYIColor &color) |
| |
| const CYIColor & | GetBackgroundColor () const |
| |
| void | SetBorderThickness (float fThickness) |
| |
| float | GetBorderThickness () const |
| |
| void | SetBorderColor (const CYIColor &color) |
| |
| const CYIColor & | GetBorderColor () const |
| |
| void | SetCornerRadius (float fRadius) |
| |
| void | SetCornerRadiuses (float fTopLeftRadius, float fTopRightRadius, float fBottomLeftRadius, float fBottomRightRadius) |
| |
| float | GetTopLeftCornerRadius () const |
| |
| float | GetTopRightCornerRadius () const |
| |
| float | GetBottomLeftCornerRadius () const |
| |
| float | GetBottomRightCornerRadius () const |
| |
| void | SetOverflowMode (OVERFLOW_MODE eMode) |
| |
| OVERFLOW_MODE | GetOverflowMode () const |
| |
| | CYISceneView () |
| |
| virtual | ~CYISceneView () |
| |
| bool | BuildFromTemplate (CYISceneManager *pSceneManager, const std::shared_ptr< CYIAssetViewTemplate > &pAssetViewTemplate, CYISceneManager::MISSING_CLASS_HANDLING_MODE eMissingHandlingMode=CYISceneManager::ABORT) |
| |
| bool | IsInitialized () const |
| |
| void | SetClippingAreaNode (CYISceneNode *pClippingNode) |
| |
| virtual bool | GetProperty (const CYIString &propertyName, CYIString *pValue) const override |
| |
| void | EnableDefaultHitZone () |
| |
| bool | IsResponsiveLayoutEnabled () const |
| |
| void | EnableResponsiveLayout () |
| |
| void | DisableResponsiveLayout () |
| |
| void | AddAnchor (YI_ANCHOR_TYPE anchorType) |
| |
| YI_ANCHOR_DATA | GetAnchor (YI_ANCHOR_TYPE anchorType) const |
| |
| virtual const CYISceneView::AssetRequirement * | GetAssetRequirements (uint32_t *pRequirementCount) |
| |
| CYIAbstractTimeline * | GetInTimeline () const |
| |
| CYIAbstractTimeline * | GetOutTimeline () const |
| |
| CYIAbstractTimeline * | GetFocusInTimeline () const |
| |
| CYIAbstractTimeline * | GetFocusOutTimeline () const |
| |
| virtual bool | HandlesFocusInDescendants () const |
| |
| virtual bool | RequestFocus (CYIFocus::FOCUS_DIRECTION eDirection=CYIFocus::FOCUS_FORWARD, CYIFocus::FOCUS_ROOT_RULE eFocusRootRule=CYIFocus::FOCUS_ROOT_DESCENDANTS_UPDATE_CONTEXT, const CYIAABB &previousFocusRect=CYIAABB(), const CYIFocusSearchOptions &options=CYIFocusSearchOptions()) |
| |
| bool | HasFocus () const |
| |
| void | SetFocusable (bool bFocusable) |
| |
| bool | IsFocusable () const |
| |
| bool | CanBeFocused () const |
| |
| void | SetNextFocus (CYISceneView *pView, CYIFocus::FOCUS_DIRECTION eDirection) |
| |
| CYISceneView * | GetNextFocus (CYIFocus::FOCUS_DIRECTION eDirection) const |
| |
| void | SetInitiallyFocusedView (CYISceneView *pView) |
| |
| CYISceneView * | GetInitiallyFocusedView () const |
| |
| CYISceneView * | FindNextFocus (CYIFocus::FOCUS_DIRECTION eDirection, const CYIFocusSearchOptions &options=CYIFocusSearchOptions()) const |
| |
| CYISceneView * | FindNextFocus (CYIFocus::FOCUS_DIRECTION eDirection, CYIAABB &screenSpaceFocusRegion, const CYIFocusSearchOptions &options=CYIFocusSearchOptions()) const |
| |
| virtual CYISceneView * | FindNextFocusInDescendants (const CYISceneView *pCurrentFocusView, CYIFocus::FOCUS_DIRECTION eDirection, CYIAABB &screenSpaceFocusRegion, const CYIFocusSearchOptions &options=CYIFocusSearchOptions()) const |
| |
| const CYISceneNode * | GetFocusRoot () const |
| |
| CYISceneView * | GetFocusHandler () const |
| |
| virtual void | OnFocusGained () |
| |
| virtual void | FocusGained () |
| |
| virtual void | OnFocusLost () |
| |
| virtual void | FocusLost () |
| |
| const std::shared_ptr< CYIAssetViewTemplate > & | GetViewTemplate () const |
| |
| const std::vector< CYIString > & | GetChildTemplateNames () |
| |
| virtual CYIAbstractTimeline * | GetTimeline (const CYIString &rMarkerName, TIMELINE_GET_MODE eMode=GET_DEFAULT) |
| |
| CYIAbstractTimeline * | GetTimeline (CYIMarkerData::MARKER_ID eID, TIMELINE_GET_MODE eMode=GET_DEFAULT) |
| |
| std::map< CYIString, CYITimeline * > | GetTimelines () const |
| |
| bool | FindTimeline (CYIAbstractTimeline *&pTimeline, const CYIString &markerName, FETCH_TYPE eType, const CYIString &tag="", TIMELINE_GET_MODE eMode=GET_DEFAULT) |
| |
| CYITimelineGroup * | GetTimelineGroup (const CYIString &markerName) |
| |
| std::unique_ptr< CYITimelineGroup > | BuildTimelineGroup (const CYIString &markerName) |
| |
| void | BuildAnchorList () |
| |
| virtual void | Reset () |
| |
| void | SetLayout (std::unique_ptr< CYILayout > pLayout) |
| |
| const CYILayout * | GetLayout () const |
| |
| CYILayout * | GetLayout () |
| |
| virtual void | Measure (const MeasureSpec &widthSpec, const MeasureSpec &heightSpec, const MeasureSpec &depthSpec) override |
| |
| virtual void | ApplyMeasurements () override |
| |
| | CYISceneNode () |
| |
| virtual | ~CYISceneNode () |
| |
| void | ForceDirty () |
| |
| void | ClearDirtyFlag () |
| |
| void | SetDirtyFlag (DirtyFlag eDirtyFlag) |
| |
| DirtyFlag | GetDirtyFlag () const |
| |
| DirtyFlag | GetPreviousDirtyFlag () const |
| |
| const CYIString & | GetName () const |
| |
| CYIString | GetUniqueName () const |
| |
| void | SetSceneManager (CYISceneManager *pSceneManager) |
| |
| void | SetName (const CYIString &name) |
| |
| int32_t | GetID () const |
| |
| void | SetID (int32_t nID) |
| |
| uint64_t | GetUniqueID () const |
| |
| bool | AddChild (std::unique_ptr< CYISceneNode > pSceneNode) |
| |
| bool | AddChild (std::unique_ptr< CYISceneNode >, int32_t nIndex) |
| |
| bool | InsertChildAfter (CYISceneNode *pRefNode, std::unique_ptr< CYISceneNode > pSceneNode) |
| |
| std::unique_ptr< CYISceneNode > | RemoveChild (CYISceneNode *pSceneNode) |
| |
| bool | ReorderChild (uint32_t uFromIndex, uint32_t uToIndex) |
| |
| CYISceneNode * | GetParent () const |
| |
| bool | ChangeParent (CYISceneNode *pParent) |
| |
| CYISceneNode * | GetDrawParent () const |
| |
| bool | IsAncestorOf (const CYISceneNode *pNode) const |
| |
| CYISceneManager * | GetSceneManager () const |
| |
| uint32_t | GetChildCount () const |
| |
| uint32_t | GetChildCountRecursive () const |
| |
| CYISceneNode * | GetChild (uint32_t nIndex) const |
| |
| Iterator | begin (Iterator::ITERATION_MODE eMode=Iterator::IMMEDIATE_CHILDREN) const |
| |
| Iterator | end (Iterator::ITERATION_MODE eMode=Iterator::IMMEDIATE_CHILDREN) const |
| |
| ReverseIterator | rbegin (Iterator::ITERATION_MODE eMode=Iterator::IMMEDIATE_CHILDREN) const |
| |
| ReverseIterator | rend (Iterator::ITERATION_MODE eMode=Iterator::IMMEDIATE_CHILDREN) const |
| |
| CYISceneNode * | GetChild (const CYIString &sName) const |
| |
| uint32_t | GetDrawChildCount () const |
| |
| CYISceneNode * | GetDrawChild (uint32_t uIndex) const |
| |
| CYISceneNode * | GetDrawChildByID (int32_t nID) const |
| |
| template<class YI_SCENE_NODE_SUBCLASS > |
| YI_SCENE_NODE_SUBCLASS * | GetChild (uint32_t uTargetMatchedNodeCount=1) const |
| |
| template<class YI_SCENE_NODE_SUBCLASS > |
| std::list< YI_SCENE_NODE_SUBCLASS * > | GetChildren () const |
| |
| int32_t | GetIndexOfChild (const CYISceneNode *pSceneNode) const |
| |
| void | Show () |
| |
| void | Hide () |
| |
| void | SetVisibility (bool bVisible) |
| |
| void | SetOpacity (float fOpacity) |
| |
| float | GetCompositeOpacity () const |
| |
| float | GetLocalOpacity () const |
| |
| bool | IsVisible () const |
| |
| bool | IsTrulyVisible () const |
| |
| CYISceneNode * | GetNode (const CYIString &name) |
| |
| CYISceneNode * | GetNode (const CYIString &name, const CYIRuntimeTypeInfo &enforceClassType) |
| |
| CYISceneNode * | GetNode (const CYIRuntimeTypeInfo &enforceClassType) |
| |
| CYISceneNode * | GetNodeAfterTarget (const CYIRuntimeTypeInfo &enforceClassType, CYISceneNode *pStartAfterTarget) |
| |
| template<class YI_SCENE_NODE_SUBCLASS > |
| YI_SCENE_NODE_SUBCLASS * | GetNode (const CYIString &name) |
| |
| CYISceneNode * | GetNode (const int32_t nID) |
| |
| CYISceneNode * | GetNode (const int32_t nID, const CYIRuntimeTypeInfo &enforceClassType) |
| |
| template<class YI_SCENE_NODE_SUBCLASS > |
| bool | FindNode (YI_SCENE_NODE_SUBCLASS *&pNode, const CYIString &nodeName, FETCH_TYPE eType, const CYIString &tag) |
| |
| std::list< CYISceneNode * > | GetNodes (const CYIString &name) |
| |
| std::list< CYISceneNode * > | GetNodes (int32_t nID) |
| |
| std::list< CYISceneNode * > | GetNodes (const CYIRuntimeTypeInfo &enforceClassType) |
| |
| template<class YI_SCENE_NODE_SUBCLASS > |
| const YI_SCENE_NODE_SUBCLASS * | GetNode (uint32_t uTargetMatchedNodeCount=1) const |
| |
| template<class YI_SCENE_NODE_SUBCLASS > |
| YI_SCENE_NODE_SUBCLASS * | GetNode (uint32_t uTargetMatchedNodeCount=1) |
| |
| void | SetMesh (const std::shared_ptr< CYIMesh > &pMesh) |
| |
| void | SetMaterial (const std::shared_ptr< CYIMaterial > &pMaterial, uint32_t nIndex=0) |
| |
| void | AddEffect (const std::shared_ptr< CYIEffect > &pEffect) |
| |
| void | RemoveEffect (const std::shared_ptr< CYIEffect > &pEffect) |
| |
| uint32_t | GetEffectCount () const |
| |
| std::shared_ptr< CYIEffect > | GetEffect (uint32_t uIndex) const |
| |
| void | ConnectEffectsToTimelines (const CYITimelineTrack *pTrack) |
| |
| void | AddMask (std::unique_ptr< CYIMask > pMask) |
| |
| std::unique_ptr< CYIMask > | RemoveMask (const CYIMask *pMask) |
| |
| uint32_t | GetMaskCount () const |
| |
| const CYIMask * | GetMask (uint32_t uIndex) const |
| |
| CYIMask * | GetMask (uint32_t uIndex) |
| |
| const std::shared_ptr< CYIMesh > & | GetMesh () const |
| |
| uint32_t | GetMaterialCount () const |
| |
| const std::shared_ptr< CYIMaterial > | GetMaterial (uint32_t nIndex=0) const |
| |
| const std::shared_ptr< IYIUniformBufferObject > & | GetShaderUniforms () const |
| |
| void | SetMeshTransform (const glm::mat4 &rTransform) |
| |
| void | DestroyChildren () |
| |
| const glm::mat4 & | GetLocalTransform () const |
| |
| const glm::mat4 & | GetEffectTransform () const |
| |
| const glm::mat4 & | GetWorldTransform () const |
| |
| bool | Intersects (const CYISceneNode *pNode) const |
| |
| void | SetRenderTarget (const std::shared_ptr< CYIRenderTarget > &pRenderTarget) |
| |
| const std::shared_ptr< CYIRenderTarget > | GetRenderTarget () const |
| |
| const CYIAABB & | GetWorldAABB () const |
| |
| const CYIAABB & | GetLocalAABB () const |
| |
| void | SetAnchorPoint (const glm::vec3 &ref) |
| |
| void | SetAnchorPoint (float fX, float fY, float fZ) |
| |
| void | SetAnchorPointX (float fX) |
| |
| void | SetAnchorPointY (float fY) |
| |
| void | SetAnchorPointZ (float fZ) |
| |
| void | SetPosition (const glm::vec3 &ref) |
| |
| void | SetPosition (float fX, float fY, float fZ) |
| |
| void | SetPositionX (float fX) |
| |
| void | SetPositionY (float fY) |
| |
| void | SetPositionZ (float fZ) |
| |
| void | SetRotation (const glm::vec3 &fEulerDegrees) |
| |
| void | SetRotation (float fPitchDegrees, float fYawDegrees, float fRollDegrees) |
| |
| void | SetRotationX (float fPitchDegrees) |
| |
| void | SetRotationY (float fYawDegrees) |
| |
| void | SetRotationZ (float fRollDegrees) |
| |
| void | SetOrientation (float fPitchDegrees, float fYawDegrees, float fRollDegrees) |
| |
| void | SetOrientation (const glm::quat &orient) |
| |
| void | SetScale (const glm::vec3 &fScaleFactors) |
| |
| void | SetScale (float fFactorX, float fFactorY, float fFactorZ) |
| |
| void | SetScaleX (float fFactor) |
| |
| void | SetScaleY (float fFactor) |
| |
| void | SetScaleZ (float fFactor) |
| |
| const glm::vec3 & | GetPosition () const |
| |
| const glm::vec3 & | GetScale () const |
| |
| const glm::vec3 & | GetWorldScale () const |
| |
| const glm::vec3 & | GetWorldSurfaceScale () const |
| |
| const glm::vec3 & | GetRotation () const |
| |
| const glm::quat & | GetOrientation () const |
| |
| const glm::vec3 & | GetAnchorPoint () const |
| |
| virtual void | SetSize (const glm::vec3 &vSize, bool bDirtyLayout=true) |
| |
| const glm::vec3 & | GetSize () const |
| |
| const glm::vec3 & | GetInitialSize () const |
| |
| void | SetMeasuredSize (const glm::vec3 &vMeasuredSize) |
| |
| const glm::vec3 & | GetMeasuredSize () const |
| |
| void | SetInternalCustomTimelineValue (uint32_t nTrackID, const CYIVariant &value) |
| |
| virtual void | SetCustomTimelineValue (uint32_t nTrackID, const CYIVariant &value) |
| |
| void | SetClippingOn () |
| |
| void | SetClippingOff () |
| |
| bool | GetClipping () const |
| |
| void | SetClippingBox (const CYIAABB &rWorldBox) |
| |
| const CYIAABB & | GetClippingBox () const |
| |
| void | StartPropertyAnimation (YI_NODE_PROPERTY_TYPE ePropType, float fFrom, float fTo, uint32_t nDurMs, CYITimeInterpolator *pTimeInterpolator=nullptr, bool bDirtyLayout=true) |
| |
| void | StopPropertyAnimation (YI_NODE_PROPERTY_TYPE ePropType) |
| |
| void | UpdateLocalSpaceCollision (CYIActionEvent *pActionEvent) |
| |
| virtual bool | BroadcastEvent (const std::shared_ptr< CYIEventDispatcher > &pDispatcher, CYIEvent *pEvent) |
| |
| void | UpdateEventForLocalSpace (CYIActionEvent *pActionEvent, glm::vec3 &rayOrigin, glm::vec3 &rayNonOriginPoint) const |
| |
| bool | IsBoundingBoxHit (const CYIRay &rWorldSpaceRay) const |
| |
| bool | IsMeshHit (const CYIRay &rWorldSpaceRay) const |
| |
| void | DumpTree () const |
| |
| void | StartCaptureKeyboardEvents () |
| |
| void | StopCaptureKeyboardEvents () |
| |
| void | StartCaptureTrackpadEvents () |
| |
| void | StopCaptureTrackpadEvents () |
| |
| void | StartCapturePointerEvents (uint8_t uPointerID) |
| |
| void | StopCapturePointerEvents (uint8_t uPointerID) |
| |
| bool | DrawBehindChildren (CYISceneNode *pSceneNode) |
| |
| bool | DrawInFrontOfChildren (CYISceneNode *pSceneNode) |
| |
| bool | DrawBehind (CYISceneNode *pSceneNode) |
| |
| bool | DrawInFront (CYISceneNode *pSceneNode) |
| |
| bool | IsFocusRoot () const |
| |
| void | SetIsFocusRoot (bool bIsFocusRoot) |
| |
| virtual void | OnFocusGainedInDescendants () |
| |
| virtual void | FocusGainedInDescendants () |
| |
| virtual void | OnFocusLostInDescendants () |
| |
| virtual void | FocusLostInDescendants () |
| |
| virtual void | OnFocusChangedInDescendants () |
| |
| virtual void | FocusChangedInDescendants () |
| |
| virtual bool | ContainsFocusableDescendant (const CYIFocusSearchOptions &options=CYIFocusSearchOptions()) const |
| |
| void | ShowPointerDebugNode (CYIActionEvent *pActionEvent) |
| |
| void | SetUseLocalTransformAndAlpha (bool bUse) |
| |
| virtual const std::map< CYIString, CYIString > & | GetProperties () const override |
| |
| void | SetProperty (const CYIString &rPropertyName, const CYIString &rPropertyValue) |
| |
| const std::shared_ptr< CYISceneNodeProxy > & | GetSceneNodeProxy () const |
| |
| void | SetLayoutConfig (std::unique_ptr< CYILayoutConfig > pLayoutConfig) |
| |
| const CYILayoutConfig * | GetLayoutConfig (LayoutConfigFetchMode eFetchMode=LAYOUT_CONFIG_LAZY_INSTANTIATE) const |
| |
| CYILayoutConfig * | GetLayoutConfig (LayoutConfigFetchMode eFetchMode=LAYOUT_CONFIG_LAZY_INSTANTIATE) |
| |
| void | SetLayoutState (std::unique_ptr< CYILayoutState > pLayoutState) |
| |
| const CYILayoutState * | GetLayoutState () const |
| |
| CYILayoutState * | GetLayoutState () |
| |
| void | RequestLayout () |
| |
| LayoutDirtyFlag | GetLayoutDirtyFlag () const |
| |
| virtual void | SetLayoutDirtyFlag (LayoutDirtyFlag eFlag) |
| |
| CYIAbstractCameraSceneNode * | FindActiveCamera () const |
| |
| template<typename T > |
| bool | CanCastTo () const |
| |
| | CYIEventTarget () |
| |
| virtual | ~CYIEventTarget () |
| |
| bool | AddEventListener (YI_EVENT_TYPE eEventType, CYIEventHandler *pListener, EVENT_PHASE ePhase=BUBBLE) |
| |
| bool | RemoveEventListener (YI_EVENT_TYPE eEventType, CYIEventHandler *pListener, EVENT_PHASE ePhase=BUBBLE) |
| |
| void | SetSpecialTypeFlag (YI_SPECIAL_EVENT_TARGET_TYPE eType) |
| |
| void | ClearSpecialTypeFlag (YI_SPECIAL_EVENT_TARGET_TYPE eType) |
| |
| YI_SPECIAL_EVENT_TARGET_TYPE | GetSpecialTypes () const |
| |
| | CYIScriptableRTTIObject () |
| |
| virtual | ~CYIScriptableRTTIObject () |
| |
| virtual const CYIRuntimeTypeInfo * | GetRuntimeTypeInfoForScriptObject () const override |
| |
| | CYIScriptableObject () |
| |
| | CYIScriptableObject (const CYIScriptableObject &other) |
| |
| CYIScriptableObject & | operator= (const CYIScriptableObject &other) |
| |
| virtual | ~CYIScriptableObject () |
| |
| CYIBindingImplementation * | GetBindingImplementation () const |
| |
| void | SetBindingImplementation (CYIBindingImplementation *pBindingImplementation) |
| |
 Public Member Functions inherited from CYISignalHandler |
| | CYISignalHandler () |
| |
| | CYISignalHandler (const CYISignalHandler &rSignalHandler) |
| |
| virtual | ~CYISignalHandler () |
| |
| CYISignalHandler & | operator= (const CYISignalHandler &rSignalHandler) |
| |
| void | MoveToThread (CYIThread *pThread) |
| | This function allows the user to override the default thread affinity to any CYIThread that may or may not be running. More...
|
| |
| CYIThreadHandle | GetThreadAffinity () const |
| |
| void | SetThreadAffinity (const CYIThreadHandle &rThreadAffinity) |
| |
| virtual bool | IsConnected () const |
| |
| virtual bool | IsConnected (const CYISignalBase &rSignal) const |
| |
| void | Disconnect (CYISignalBase &rSignal) |
| |
| void | DisconnectFromAllSignals () |
| |
| | Listener () |
| |
| virtual | ~Listener () |
| |
| virtual void | OnThreadStarted (CYIThread *) |
| |
| virtual void | OnThreadTerminated (CYIThread *) |
| |
| virtual void | OnThreadFinished (CYIThread *) |
| |
| virtual | ~IYIPropertiesSource () |
| |
| Public Member Functions inherited from CYIEventHandler |
| | CYIEventHandler () |
| |
| | CYIEventHandler (const CYIEventHandler &) |
| |
| virtual | ~CYIEventHandler () |
| |
| CYIEventHandler & | operator= (const CYIEventHandler &) |
| |
| bool | RegisterEventFilter (CYIEventFilter *pFilter) |
| |
| bool | UnregisterEventFilter (CYIEventFilter *pFilter) |
| |
| bool | PreFilter (const std::shared_ptr< CYIEventDispatcher > &pDispatcher, CYIEvent *pEvent) |
| |
| bool | PostFilter (const std::shared_ptr< CYIEventDispatcher > &pDispatcher, CYIEvent *pEvent) |
| |
| bool | AreEventsEnabled () const |
| |
| void | EnableEvents (bool bEnable) |
| |
|
| static void | RegisterAllViews () |
| |
| static void | RegisterAllSceneNodes () |
| |
| CYISignal< CYISceneView * > | GainedFocus |
| | Emitted when focus has entered this view. More...
|
| |
| CYISignal< CYISceneView * > | LostFocus |
| | Emitted when focus has left this view. More...
|
| |
| CYISignal< CYISceneNode *, YI_NODE_PROPERTY_TYPE > | PropertyAnimationComplete |
| |
| CYISignal | DescendantGainedFocus |
| | Emitted when focus has entered this tree. More...
|
| |
| CYISignal | DescendantLostFocus |
| | Emitted when focus has left this tree. More...
|
| |
| CYISignal | DescendantsChangedFocus |
| | Emitted when focus has changed within this tree. More...
|
| |
| static const float | OPACITY_NOT_VISIBLE_EPSILON |
| |
| void | UpdateClipping () |
| |
| virtual void | WorldScaleUpdated () override |
| |
| virtual void | WorldBoundingBoxUpdated () override |
| |
| virtual void | OnViewReflowed (const glm::vec3 &worldScale) |
| |
| virtual void | ViewReflowed (const glm::vec3 &worldScale) |
| |
| virtual bool | HandleEvent (const std::shared_ptr< CYIEventDispatcher > &pDispatcher, CYIEvent *pEvent) override |
| |
| virtual bool | ProcessEvent (const std::shared_ptr< CYIEventDispatcher > &pDispatcher, CYIEvent *pEvent) override |
| |
| void | UpdateResponsiveLayoutAnchors () |
| |
| virtual void | SizeChanged () override |
| |
| virtual void | ChildNeedsLayout () override |
| |
| virtual void | LayoutDirtied () override |
| |
| virtual void | ChildAdded (CYISceneNode *pChild) override |
| |
| virtual void | ChildRemoved (CYISceneNode *pChild) override |
| |
| virtual void | ChildVisibilityChanged (CYISceneNode *pChild) override |
| |
| void | OnViewIsInAnimatedPosition () |
| |
| void | OnViewIsGoingOutOfAnimatedPosition () |
| |
| void | SetInTimeline (CYIAbstractTimeline *pTimeline) |
| |
| void | SetOutTimeline (CYIAbstractTimeline *pTimeline) |
| |
| virtual void | OnInit () |
| |
| bool | TryRequestFocusOnInitiallyFocusedView () |
| |
| void | Update (bool bForceDirty=false) |
| |
| virtual void | OnUpdateBegin () |
| |
| virtual void | UpdateBegin () |
| |
| virtual void | OnUpdateEnd () |
| |
| virtual void | UpdateEnd () |
| |
| virtual void | OnDirtyFlagChanged () |
| |
| virtual void | DirtyFlagChanged () |
| |
| virtual void | OnTransformUpdated () |
| |
| virtual void | TransformUpdated () |
| |
| virtual void | OnWorldScaleUpdated () |
| |
| virtual void | OnWorldSurfaceScaleUpdated () |
| |
| virtual void | WorldSurfaceScaleUpdated () |
| |
| virtual void | OnVisibilityUpdated () |
| |
| virtual void | VisibilityUpdated () |
| |
| virtual void | OnCompositeOpacityUpdated () |
| |
| virtual void | CompositeOpacityUpdated () |
| |
| virtual void | OnWorldBoundingBoxUpdated () |
| |
| virtual void | OnLocalBoundingBoxUpdated () |
| |
| virtual void | LocalBoundingBoxUpdated () |
| |
| virtual void | OnChildAdded (CYISceneNode *pChild) |
| |
| virtual void | OnChildRemoved (CYISceneNode *pChild) |
| |
| virtual void | OnSizeChanged () |
| |
| virtual void | CalculateLocalTransform (glm::mat4 *pTransform) const |
| |
| virtual void | OnChildVisibilityChanged (CYISceneNode *pChild) |
| |
| LayoutDirtyFlag | GetCurrentLayoutDirtyFlag () const |
| |
| virtual CYIString | GetDumpTreeString () const |
| |
| void | DumpTree (int32_t nIndentLevel) const |
| |
| void | SetShaderUniforms () |
| |
| virtual void | SetCustomUniforms () |
| |
| template<class T > |
| void | SetNodeType () |
| |
| virtual CYISceneNode * | GetNodeFromChildren (const CYIString &name) |
| |
| virtual CYISceneNode * | GetNodeFromChildren (const int32_t nID) |
| |
| virtual CYISceneNode * | GetNodeFromChildren (const CYIRuntimeTypeInfo &enforceClassType) |
| |
| CYISceneNode * | GetNodeFromChildrenAfterTarget (const CYIRuntimeTypeInfo &enforceClassType, bool *pbTargetReached, CYISceneNode *pStartAfterTarget) |
| |
| virtual std::pair< const CYIRuntimeTypeInfo *, const void * > | GetRuntimeTypeInfoWithObject () const =0 |
| |
| bool | m_bStopEventPropagation |
| |
| bool | m_bResponsiveLayoutEnabled |
| |
| bool | m_bSceneTreeBuilt |
| |
| bool | m_bInAnimatedPosition |
| |
| CYISceneNode * | m_pClippingNode |
| |
| CYIAbstractTimeline * | m_pFocusInTimeline |
| |
| CYIAbstractTimeline * | m_pFocusOutTimeline |
| |
| std::unique_ptr< CYILayout > | m_pLayout |
| |
| std::shared_ptr< CYIAssetViewTemplate > | m_pAssetViewTemplate |
| |
| std::shared_ptr< CYISceneNodeProxy > | m_pInitiallyFocusedView |
| |
| std::multimap< YI_ANCHOR_TYPE, YI_ANCHOR_DATA > | m_anchors |
| |
| std::map< CYIString, std::unique_ptr< CYITimeline > > | m_timelines |
| |
| std::map< CYIString, std::unique_ptr< CYIParallelTimelineGroup > > | m_timelineGroups |
| |
| CYIString | m_name |
| |
| CYISceneNode * | m_pParent |
| |
| CYISceneNode * | m_pDrawParent |
| |
| CYISceneManager * | m_pSceneManager |
| |
| std::vector< std::unique_ptr< CYISceneNode > > | m_children |
| |
| std::vector< CYISceneNode * > | m_drawChildren |
| |
| std::map< CYIString, CYIString > | m_Properties |
| |
| std::vector< std::shared_ptr< CYIMaterial > > | m_pMaterials |
| |
| std::vector< std::unique_ptr< CYIMask > > | m_Masks |
| |
| std::vector< std::shared_ptr< CYIEffect > > | m_Effects |
| |
| std::vector< PropertyAnimation * > | m_propertyAnimations |
| |
| float | m_fLocalOpacity |
| |
| CYIAABB | m_WSClipBox |
| |
| glm::mat4 | m_EffectTransform |
| |
| glm::quat | m_Orientation |
| |
| glm::vec3 | m_Rotate |
| |
| glm::vec3 | m_AnchorPoint |
| |
| glm::vec3 | m_Position |
| |
| glm::vec3 | m_Scale |
| |
| glm::vec3 | m_vSize |
| |
| glm::vec3 | m_vInitialSize |
| |
| glm::vec3 | m_vMeasuredSize |
| |
| glm::vec3 | m_vlsLastCollision |
| |
| bool | m_bClip |
| |
| bool | m_bIsRotated |
| |
| bool | m_bIsOriented |
| |
| bool | m_bLocalVisibility |
| |
| int32_t | m_nID |
| |
| uint64_t | m_uGUID |
| |
| std::shared_ptr< CYIRenderTarget > | m_pRenderTarget |
| |
| std::shared_ptr< CYIMesh > | m_pMesh |
| |
| std::shared_ptr< IYIUniformBufferObject > | m_pShaderUniforms |
| |
| YI_SPECIAL_EVENT_TARGET_TYPE | m_eSpecialTypes |
| |
| std::vector< EventListenerEntry > | m_listeners |
| |
| Protected Attributes inherited from CYIEventHandler |
| bool | m_bEnableEvents |
| |
1.8.11
