158 / 601
C31
Construction Options
Specifications and Options
Wastebasket Drawer Partition
WDP
• Partition between the wastebasket and top
drawer
• Available on all Wastebasket cabinets with a
top drawer
•
Not
available with Integrated Decorative End
(DE) Option
•
Not
available with Operational End Door
(OE) option
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
New
Grey color coding indicates new product, size or code.
Recessed Toe Kick
RTKB
Both
RTKL
Left
RTKR
Right
• Most Base, Tall and Vanity cabinets can be
ordered with a recessed toe kick. Consult
option availability chart for desired cabinet
• You
must
specify end or ends to receive
recessed toe kick
• Painted hardwood supplied for EverCore™
• Additional bottom support is recommended
when using RTKB on peninsula cabinets
wider than 27”
• RTK and WR
not
available on same cabinet
except when combining WR_K and RTKP
options
•
Not
available on 93” and 96” high tall
cabinets
We recommend Recessed Toe Kicks
(RTKR or RTKL) on base cabinets at
the end of peninsula runs or island applications.
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
l
RTK
RTKP
3
B30-RTKL
Recessedtoekick left
B30-RTKR
Recessedtoekickright
3
3
3
B30-RTKB
Recessedtoekickboth
/ ˝
/ ˝
/ ˝
/ ˝
Recessed Toe Kick Peninsula
RTKP
Back
RTKPB
Back and both sides
RTKPL
Back and left side
RTKPR
Back and right side
• Select Base and Office Cabinets may be
ordered with a Recessed Toe Kick on the
back (Peninsula) side. Consult option
availability chart for desired cabinet
• You
must
specify end or ends to receive
Recessed Toe Kick Peninsula
• Painted hardwood supplied for EverCore™
• Additional bottom support is recommended
when using RTKPB on cabinets wider than
27”
• RTK and WR
not
available on same cabinet
except when combining WR_K and RTKP
options
•
Not
available on cabinets less than 21˝ deep
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
l
RTKP
RTKP
RTKPB
RTKPL
RTKPR
Void Toe Kick
VTK
• Select Base, Tall, Office, Furniture and Vanity
Cabinets may be ordered without the toe
kick
• Allows decorative feet to be used under
cabinet
• Decorative feet or legs should support the
cabinet by way of the end panels,
not
the
cabinet floor
• Full overlay door styles are
not
to be placed
directly on the floor
• Cabinets are
not
intended to be free-
standing units, they
must
be attached to a
wall stud or anchored to the floor to achieve
sufficient stability
•
Not
available on Passport cabinets
•
Not
available on 93” and 96” high tall
cabinets
•
Not
available with Wide Rail (WR) option
•
Not
available on cabinets with a decorative toe kick
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
