C26
Construction Options
Specifications and Options
Decorative Wide Rail Options
Wide Rail Plain
WRB
WRK
WRP
Wide Rail Arch No Fret
s
WRARB
s
WRARK
s
WRARP
Wide Rail Corbel
WRCBB
WRCBK
WRCBP
Wide Rail Cove
WRCVB
WRCVK
WRCVP
Wide Rail Crown
WRCRB
WRCRK
WRCRP
Wide Rail Furniture
WRFB
WRFK
WRFP
Wide Rail Shaker
WRSHB
WRSHK
WRSHP
Wide Rail Victorian
WRVIB
WRVIK
WRVIP
• We offer many base and tall cabinets with
a variety of wide bottom rail options (WR).
Consult option availability chart for your
desired cabinet
• B=Both
K=Kitchen side
P=Peninsula side
• Decorative wide bottom rail only available
on cabinets 15” or wider
• Ships with black toe kick installed, except
for Wide Rail Plain (WR). Matching toe kick
must
be ordered separately and installed
before cabinet is installed
• RTK and WR
not
available on same cabinet
except when combining WR_K and RTKP options
• In quartersawn door styles, Wide Rail Plain will be
quartersawn; all other decorative wide rail options will
be plain sawn
•
Not
available on 93” and 96” high tall cabinets
•
Not
available in Sturbridge, except for WIde Rail Plain
(WR). Hayward and Manchester supplied plain sawn
• Painted hardwood supplied for EverCore™ and Laminate
• Order Example: B30-WRAK
Remember, WRA-Wide Bottom Rail Arched
Fret, WRSH-Shaker, WRA-Arched, WRAR-
Arched No Fret, WRCR-Crown, WRCB-Corbel,
WRCV-Cove, WRF-Furniture and WRVI-Victorian come
with black toe kick behind. To finish the toe kick you
must
order MTK8 or WMTK8 and apply it BEFORE the
cabinets are installed.
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
l
WR
XS
XSG
GD
RTK
RTKP
WRAR
WRB
WRCB
WRF
WRVI
WRSH
WRCV
WRCR
Double arch
36˝ or wider
s
Not
available in Alder–Rustic door styles
Extended Stile
Base
B3 XB
B3 XR or L
PB3 XBB
PB3 XR or LB
PB3 XR or LK
PB3 XBK or P
PB3 XR or LP
Wall
W3 XB
W3 XR or L
PW3 XBB
PW3 XR or LB
PW3 XR or LK
PW3 XBK or P
PW3 XR or LP
Tall
T3 XB
T3 XR or L
Vanity
V3 XB
V3 XR or L
• 3” extended stiles are available. Stiles may
be extended left, right or both. Consult
option availability chart (XS) for your desired
cabinet
• Order Example: B12L-B3XL. Order
designation XL means 3” extended stile left,
overall cabinet width 15”
• Use wall nomenclature for Furniture cabinets
up to 66˝ high
• Painted hardwood supplied for EverCore™
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
l
XS
XSG
GD
RTK
RTKP
Cabinets
Left
Right
Left &
Right
Peninsula Base
(Kitchen side)
PB3XLK PB3XRK PB3XBK
Peninsula Base
(Peninsula side)
PB3XLP PB3XRP PB3XBP
Peninsula Base
(Both sides)
PB3XLB PB3XRB PB3XBB
Cabinets
Left
Right
Left &
Right
Peninsula Wall
(Kitchen side)
PW3XLK PW3XRK PW3XBK
Peninsula Wall
(Peninsula side)
PW3XLP PW3XRP PW3XBP
Peninsula Wall
(Both sides)
PW3XLB PW3XRB PW3XBB
Cabinets
Left
Right
Left &
Right
Wall
W3XL
W3XR W3XB
Tall
T3XL
T3XR T3XB
Base
B3XL
B3XR
B3XB
Vanity
V3XL
V3XR V3XB
