Construction Options
Specifications and Options
Operational End
Base
BOE R or L
BOE B
Tall
TOE R or L
Vanity
VOE R or L
VOE B
Wall
12”-33” H
WOE R or L•1
WOE B•1
36-54” H
WOE R or L•2
WOE B•2
• Operational End (OE) will be attached to
2 1/2” frame stiles
•
Not
available on both ends of Tall cabinets
• Stacking configuration of Operational End
(OE) will mimic the face of the selected
cabinet; BUTT doors are
not
provided, single
hinged door only
• Recessed Toe Kick (RTK) is standard on Base,
Tall and Vanity cabinets
• If Wide Rail (WR) is selected, the side and
front will have a wide rail
• Matching Interior (MI) is
not
standard but
can be added as an option
•
Not
available on Peninsula cabinets, Wine
Cabinets, Lattice Cabinets, Tambour Cabinets, Appliance
Cabinets with Appliance Opening or Cabinets containing
Rollout Trays (ROT)
• Operational End (OE) is
not
available with Increased
Depth (ID) or Reduced Depth (RD) options
• Wall Operational End - Both (WOE.B) or any combination
of Wall Operational Ends & Decorative Wall Ends (DWE_)
should only be used on wall cabinets that are planned
to be supported from underneath, placed on a floor or
placed on a counter top. Wall cabinets are not intended to
be installed independently without additional support
• To get glass doors (GD) on Operational Ends (OE),
replacement doors with glass must bee ordered separately
and changed out in the field
• Mullion doors and Camed glass designs are not available
for 12” deep cabinets with Operational Ends (OE); the
doors are
not
wide enough to accommodate these
decorative door/glass types
Whisper Touch Angle Restrictor Clips
(WTHARC) are recommended for additional
decorative hardware clearance
PE
APC
APFC
FPEB
MI
DE
l
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
New
Grey color coding indicates new product, size or code.
Reduced Depth
One Dimension
RD
• Many cabinets can be reduced to your
desired depth in 1/16” increments. We do
have suggested minimums that control
function of cabinets. See chart
• Any cabinet reduced in depth to less than
4 5/8” will be shipped as a Cabinet Front
Only (CFO)
• Consult option availability chart for your
desired cabinet
• Order Example: B24R-RD reduced depth to
20 1/4”
PE
APC
APFC
FPEB
MI
DE
OE
l
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
Reduced Depth
Sugg.
Min.
Cabinets Reason
4 5/8"
All
Minimum for shelf hole drilling
9"
PB
Minimum for toe kick notch
Less than 9” WR is mandatory
10"
WZA Minimum allowed
10 5/8”
WZA Minimum for shelf
12”
BZA Minimum allowed
12”
Cabinets
with drawers
Minimum for working drawer
Less than 12” depth will have false drawer front
18”
BEA
WEA Minimum allowed
12”
WWH Wine Storage section always 12” deep
Cabinet
Drawer
Box Depth
24"-27"
20 43/64"
21"-23 15/16" 17 23/32"
18"-20 15/16" 14 49/64"
15"-17 15/16" 11 13/16"
12"-14 15/16"
8 55/64"
less than 12"
No drawer
