152 / 601
C25
Construction Options
Specifications and Options
Mullion Strip Oven Cabinet–Void Center Stile
MSOTB
• On 33” and 39” wide single oven cabinets the
center stile can be removed from the upper and
lower sections. When this is done, a mullion strip
is attached to the left doors
• Solid wood
•
Not
available with butt door cabinets
• Painted hardwood supplied for EverCore™
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Order Example: OC332484S-MSOTB
•
Note
: This option applies only to the OC 33_S and
OC 39_S cabinets
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
Top Wide Rail
TWRB
Both Sides
TWRK
Kitchen Side
TWRP
Peninsula Side
• We offer many base and vanity cabinets with a
Top Wide Rail option. Consult option availability
chart for your desired cabinet
• When Both Sides are selected, the cabinet will
not
have a drawer box or drawer fronts
• When Kitchen side is selected, the drawer box
will be three inches shallower than the standard
drawer box and will open to the Peninsula side
• When Peninsula side is selected, the drawer box
will be three inches shallower than the standard
drawer box and will open to the Kitchen side. See
Illustration.
• Quartersawn door styles have quartersawn top
wide rail, cabinet frame is plain sawn wood
• Painted hardwood supplied for EverCore™
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
l
TWR
WR
XS
XSG
GD
RTK
RTKP
* e reveal on a cabinet with TWR varies
depending on the door overlay. See chart.
8˝*
Peninsula side
Kitchen side
Overlay 1/2˝ Full
Reveal
7 ½ ˝ 6 ⅞ ˝
Wall Top Wide Rail
WTWR
7 1/2”
• Many wall cabinets can be ordered with a wide
top rail. Consult option availability chart for your
desired cabinet.
• Wall Top Wide Rail (WTWR) available on 12˝–36˝
high cabinets only
•
Not
available on 27” high cabinets
• This option will add 6˝ to the interior and exterior
nominal height
• Quartersawn door styles have quartersawn top
wide rail, cabinet frame is plain sawn wood
• Top rail on 18˝ high cabinets will be 7˝, on 24˝
high cabinets 8˝, all other heights 7 1/2˝
• Painted hardwood supplied for EverCore™
Remember, any replacement doors,
interior accessories or options, including
shelves, are based on the size of original
cabinet,
not
the height after WTWR is added
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
l
TWR
WR
XS
XSG
GD
RTK
RTKP
7 ½˝*
* e reveal on a cabinet with WTWR varies
depending on the door overlay. See chart.
Overlay 1/2
˝
Full
18
˝
H 6 ½
˝
5 ⅞
˝
24
˝
H
7 ½
˝
6 ⅞
˝
All other walls
7
˝
6
˝
Cabinet Valance Options
Corbel Valance
VCB
5 1/2”
Crown Valance
VCR
5 1/2”
Cove Valance
VCV
4 1/2”
Furniture Valance
VF
3 1/2”
Shaker Arched Valance
VSH
5 1/2”
Straight Rail Valance
VST
1 1/2”
VTWR
6”
Victorian Valance
VVIC
5 1/2”
• On Furniture Cabinets and Wall Open Cabinets
(WOC), the top rail can be ordered with an
optional decorative valance
• Furniture cabinets are manufactured with a
Furniture Valance as standard
• WOC cabinets are manufactured with no valance
as standard
• Valance options available in cabinets 15˝ and
wider
• Painted hardwood supplied for EverCore™ and
Laminate
• Sturbridge Oak Square will be supplied in
plainsawn oak
• Order Example: FBS181248-VST
• Order Example: WOC3030-VCR
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VCB
VCR
VSH
VVIC
VST
VTWR
VF
VCV
