C23
Construction Options
Specifications and Options
Increased Depth
One Dimension
ID
• Many wall cabinets can be increased to a 24” depth, in 1/16”
increments. Consult option availability chart for your desired
cabinet
• Any wall cabinet over 24˝ wide, at least 30˝ high with a depth
greater than 12˝
must
be installed between two cabinets, a
cabinet and a wall or supported from below. The same is also
true for cabinets with BUTT doors
• Order Example: W2430R-ID increased depth to 16 1/4”
• Maximum Increased Depth (ID) for peninsula wall cabinets is
15˝
•
Note
: Maximum cabinet width for this option is 36”
PE
APC
APFC
FPEB
MI
DE
OE
RD
l
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
15˝
Cabinet Front Only
CFO
• Front frame and appropriate doors and drawer fronts only
• Toe kick attached where applicable except 93” and 96” tall
• Extended stiles available
We recommend using this option on cabinetry
containing no factory installed accessories, since all
cabinet components will be eliminated except face
frame, doors and drawer fonts.For example, order EZR36L-CFO
instead of EZR36L.WSS-CFO or B18L-CFO instead of B18L.FWT-
CFO
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
B30-CFO
W3030-CFO
U302484-CFO
VSB242134-CFO
Inverted Frame
IF
• Most Base and Vanity cabinets can be ordered with an Inverted
Frame (IF). Consult option availability chart for your desired
cabinet
• Bottom drawer box will be 2 1/4” deep
• Factory installed Roll-out Trays (ROT) are
not
available
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
l
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
B30
Standard
B30-IF
Inverted Frame
Mullion Strip Wall–Void Center Stile
MSW
• On double door cabinets (30˝–36˝wide, up to 42˝ high) the
center stile can be removed. When this is done, a mullion strip is
attached to the left door. Order Example: W3030-MSW
• Solid wood
• Painted hardwood supplied for EverCore™
• Painted or Stained hardwood supplied for Woodgrain Laminate
door styles
• Any wall cabinet over 24˝ wide, at least 30˝ high with a depth
greater than 12˝
must
be installed between two cabinets, a
cabinet and a wall or supported from below. The same is also
true for cabinets with BUTT doors
•
Not
available on Peninsula cabinets
•
Not
available with butt door cabinets
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
