154 / 601
C27
Construction Options
Specifications and Options
Fluted Extended Stile
Base
FB3 XB
FB3 XR or L
FPB3 XBB
FPB3 XR or LB
FPB3 XR or LK
FPB3 XBK or P
FPB3 XR or LP
Wall
FW3 XB
FW3 XR or L
FPW3 XBB
FPW3 XR or LB
FPW3 XR or LK
FPW3 XBK or P
FPW3 XR or LP
Tall
FT3 XB
FT3 XR or L
Vanity
FV3 XB
FV3 XR or L
• 3” extended stiles are available. Stiles may
be extended left, right or both. Consult
option availability chart (XS) for your desired
cabinet
• Use wall nomenclature for Furniture cabinets
up to 66˝ high
• Minimum cabinet height 12˝
• Painted hardwood supplied for EverCore™
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
• Order Example: B12L-FB3XL. Order
designation XL means 3˝ extended stile left,
overall cabinet width 15˝.
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
l
XS
XSG
GD
RTK
RTKP
Cabinets
Left
Right
Left &
Right
Peninsula Base
(Kitchen side)
FPB3XLK FPB3XRK FPB3XBK
Peninsula Base
(Peninsula side)
FPB3XLP FPB3XRP FPB3XBP
Peninsula Base
(Both sides)
FPB3XLB FPB3XRB FPB3XBB
Cabinets
Left
Right
Left &
Right
Peninsula Wall
(Kitchen side)
FPW3XLK FPW3XRK FPW3XBK
Peninsula Wall
(Peninsula side)
FPW3XLP FPW3XRP FPW3XBP
Peninsula Wall
(Both sides)
FPW3XLB FPW3XRB FPW3XBB
Cabinets
Left
Right
Left &
Right
Wall
FW3XL
FW3XR FW3XB
Tall
FT3XL
FT3XR FT3XB
Base
FB3XL
FB3XR
FB3XB
Vanity
FV3XL
FV3XR FV3XB
Integrated Extended Stile
Base
BG3 XB
BG3 XR or L
Wall
WG3 XB
WG3 XR or L
• 3˝ integrated extended stiles are available.
Stiles may be extended left, right or both.
Consult option availability chart (XSG) for
your desired cabinet.
• Roll-out Trays (ROT) and Deep Roll-out Trays
(DROT)
cannot
be added to base cabinets
with this option
• WG3XB is
not
available on wall cabinets that
have a built-in center stile
• Painted hardwood supplied for EverCore™
• Order Example: B12L-BG3XL. Order
designation G3XL means 3˝ integrated
extended stile left, overall cabinet width 15˝.
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
l
XSG
GD
RTK
RTKP
Fluted Integrated Extended Stile
Base
FBG3 XB
FBG3 XR or L
Wall
FWG3 XB
FWG3 XR or L
• 3˝ integrated extended stiles are available.
Stiles may be extended left, right or both.
Consult option availability chart (XSG) for
your desired cabinet.
• FWG3XB is
not
available on wall cabinets
that have a built-in center stile
• Painted hardwood supplied for EverCore™
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
• Order Example: B12L-FBG3XL. Order
designation G3XL means 3˝ integrated
extended stile left, overall cabinet width 15˝.
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
l
XSG
GD
RTK
RTKP
