Specifications and Options
C32
Finger Pull Routing
FPR
• Finger Pull Routing (FPR) is done on the
backside of the door or drawer front,
opposite of hinging
• Available on Fox Hill Roman & Square–Half,
Geneva–Half and Thornton–Half
• You
must
specify FPR after each cabinet that
requires Finger Pull Routing
• Example: B18R•FH-FPR
• Drawer heads 30” and wider will receive two
routs
• False fronts on sink bases will be routed with
this option
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Pull centered
at bottom
3˝
Base Drawer Front
B12”–B27”
Base Drawer Front
B30”–B48”
Two pulls
at bottom
3˝
3˝ 6˝
6˝
Standard Base
Cabinet Door Pull
3˝
1˝
Standard Wall
Cabinet Door Pull
Door
Top
Door
Bottom
3˝
1˝
Void All Doors and Drawer Fronts
VDA
• All cabinets can be ordered with VDA.
This option removes all doors and drawer
fronts. Drawer boxes remain. Hinges are
not
included
•
Note:
VDA only removes doors and drawer
fronts. Tambour units, panels and center
stiles will still be attached.
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Void Doors Only
VDO
• Cabinets with a door and drawer
combination may be ordered with VDO. This
option removes all doors. Drawer fronts and
boxes remain. Hinges are
not
included.
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Construction Options
