Specifications and Options
C24
Mullion Strip Utility Top–Void Center Stile
MSUT
• On double door cabinets (30” or wider) the
center stile can be removed from the upper
section of a tall cabinet. When this is done, a
mullion strip is attached to the left door.
• Solid wood
• Painted hardwood supplied for EverCore™
• If Inverted Frame (IF) option is chosen with
this option, the smaller section, now on
bottom, will have the mullion strip
•
Not
available on cabinets with standard
Mullion Strip Base (MSB). Example: Multi-
Storage Pantry (MSP), Utility Roll-out Tray
(U-ROT).
•
Not
available with butt door cabinets
• Example: U302484-MSUT
•
Note:
MSUB and MSUT
not
available on same
cabinet
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Mullion Strip Utility Bottom–Void Center Stile
MSUB
• On double door cabinets (30” or wider) the
center stile can be removed from the lower
section of a tall cabinet. When this is done, a
mullion strip is attached to the left door
• Solid wood
• Painted hardwood supplied for EverCore™
• If Inverted Frame (IF) option is chosen with
this option, the larger section, now on top,
will have the mullion strip
•
Not
available with butt door cabinets
• Example: U302484-MSUB
•
Note:
MSUB and MSUT
not
available on
same cabinet
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Mullion Strip Oven Cabinet–Void Center Stile
MSOTB
• On 33” and 39” wide single oven cabinets the
center stile can be removed from the upper
and lower sections. When this is done, a
mullion strip is attached to the left doors.
• Solid wood
•
Not
available with butt door cabinets
• Example: OC332484S-MSOTB
• Painted hardwood supplied for EverCore™
•
Note:
This option applies only to the OC
33_S and OC 39_S cabinets
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Top Wide Rail
TWRB
Both Sides
TWRK
Kitchen Side
TWRP
Peninsula Side
• We offer many base and vanity cabinets
with a Top Wide Rail option. Consult option
availability chart for your desired cabinet.
• No drawer or drawer front
• Quartersawn door styles have quartersawn
top wide rail, cabinet frame is plain sawn
wood
• Painted hardwood supplied for EverCore™
• When TWRP is selected, the drawer box will
be three inches shallower than the standard
drawer box. See illustration.
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
l
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
* e reveal on a cabinet with TWR varies
depending on the door overlay. See chart.
8˝*
Peninsula side
Kitchen side
Overlay 1/2˝ Full
Reveal
7 ½ ˝ 6 ⅞ ˝
Construction Options
