Specifications and Options
C21
Construction Options
Contrasting Back Option–Leather Back
CPLB •COL
Cognac Leather
CPLB •ONL
Onyx Leather
• All Wall cabinets may be ordered
with an interior Leather Contrasting
Back Option unless noted (use the
appropriate back option). Wall backs
are 3/16” thick
• Example: WOC3030-CPLB•ONL
•
Note:
Color coordination with
Cognac stain will vary based on
wood species
Cleaning Tip: Use a damp,
well wrung out terry cloth
or microfiber towel to wipe
down the leather material
PE
APC
v
APFC
FPEB
v
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Gray color coding indicates new product, size or code.
Integrated Decorative End
Base
DBE B
34 1/2” H & 40” H;
12” & 24” D
DBE R or L
34 1/2” H & 40” H;
12” & 24” D
Tall/Furniture Book Shelves
DTE B
60 1/2”, 84”, 90”, 93”, & 96” H;
12”, 18”, 21” & 24” D
DTE R or L
60 1/2”, 84”, 90”, 93”, & 96” H;
12”, 18”, 21” & 24” D
Vanity
DVE B
34 1/2” H; 18” & 21” D
DVE R or L
34 1/2” H; 18” & 21” D
Wall
DWE B•1
12” H - 30” H
DWE B•2
36” H - 54” H
DWE R or L•1
12” H - 30” H
DWE R or L•2
36” H - 54” H
• Available in full overlay door styles
only
• Available on select cabinets only
• The rail height on Integrated
Decorative End will match rail height
on the door
• The overall width of a cabinet will
increase by 1/16˝, per end, when
Integrated Decorative Ends are
selected
• DWEB should only be used on wall
cabinets that are planned to be
supported from underneath, placed
on a floor, or placed on a countertop.
Wall cabinets are
not
intended to
be installed independently without
additional support.
• Toe kick notch will be standard
construction with this option
• Veneer raised panel door styles will
be supplied with a solid wood center
panel machined to resemble the
veneer center panel
•
Not
available in Laminate door styles
•
Not
available in slab door styles
• Painted hardwood supplied for
EverCore™
•
Not
available in Kensie Cherry &
Maple; Beale Cherry, Maple & Oak
door styles
•
Not
available in Increased Depth (ID)
•
Not
available in Reduced Depth (RD)
•
Not
available with Wall Top Wide Rail
(WTWR)
•
Not
available with Inverted Frame
Option (IF)
•
Note:
Cabinets ordered with
Integrated Decorative Ends will
include Matching Interior All Plywood
Furniture Construction (MIAPFC)
as standard. For details on MIAPFC
attributes, please refer to the
construction options section of this
book.
PE
APC
APFC
FPEB
MI
l
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
DWE.1
DWE.2
DBER
DBEL
DTEL
DTER
DVEL
DVER
with
VTK
w th
WR
with
RTK
