Specifications and Options
C13
Cabinet Specs
Construction
Options
Construction Options and
Modifications
v
- - Included as standard
l
- - Available with an upcharge
I
- - Available with exceptions
(Blank)
Not
available
Use the option availability chart at the right
of each item to determine which construction
options are available for your desired cabinet.
Material dimensions may vary slightly based
on lumber industry standards.
Specification subject to change without notice.
PE - - Plywood Ends
APC - All Plywood Construction
APFC - All Plywood Furniture Construction
FPEB - Furniture Plywood Ends
MI - - Matching Interior
DE - - Integrated Decorative End
RD - - Reduced Depth
ID - - Increased Depth
IF - - Inverted Frame
TWR - Top Wide Rail
WR - Wide Bottom Rail
XS - - Extended Stile
XSG - Integrated Extended Stile
GD - Glass Doors
RTK - Recessed Toe Kick
RTKP - Recessed Toe Kick Peninsula
VTK - Void Toe Kick
Plywood Ends
PE
Full Kitchens
PEB
Individual Cabinets
• This construction option affects end panels only
• Available for full or partial kitchen orders
• 1/2” plywood end panels are available for most cabinets
• Consult the Plywood Ends (PE) option box for your desired cabinet
• End panels only are 1/2” plywood with wood veneer exterior and Natural Birch Viraguard interior
• Shelves, ceilings and floors are engineered wood with Viraguard
• To order a full kitchen with Plywood Ends, use PE in the header of your order
• To order individual line items with Plywood Ends, dash each line item with PEB; Example: W3030-
PEB
• Unless noted, plain sawn end panels will be supplied for quartersawn door styles
• Plywood End Panels do
not
receive glaze detailing
• Painted hardwood supplied for EverCore™
l
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Wood Veneer
Exterior
Natural Birch
Viraguard
Interior
Plywood
½˝
KraftMaid® Cabinetry Utilizes Some of the Best Materials Available to Build the Highest Quality Cabinets.
At KraftMaid® we continuously strive to provide products of the highest quality for all rooms of the home. In order to fulfill our
commitment to quality, you may see some material changes in some of the plywood components that we use. The material
changes will help reduce warping, expansion and contraction within the parts.
What Is In Some Of Our Plywood?
Multiple layers of wood materials, including wood veneers and medium density fiberboard (MDF), are used to create a hybrid
product containing the following benefits:
• Improved Strength and Finish Quality: Reduces expansion or contraction, which is better for a smooth, quality finish. This
process also produces a more rigid product.
• Environmentally Friendly: Supports CARB II standards. (CARB, or California Air Resource Board, is a control measure for
reduced formaldehyde emissions from composite wood products.)
Regardless of the wood material used in the various applications of our All Plywood Construction, you can feel confident that
KraftMaid Cabinetry always uses some of the highest quality materials available to help ensure durable and long-lasting cabinets.
Note:
According to the Department of Commerce, the core of hardwood and decorative plywood consists of a layer or layers of
one or more material(s) that are situated between the face and back veneers. The core may be composed of a range of materials,
including but
not
limited to veneers, particleboard, engineered wood and medium density fiberboard (MDF).
