Specifications and Options
C23
Construction Options
Inverted Frame
IF
• Most Base and Vanity cabinets can be
ordered with an Inverted Frame (IF). Consult
option availability chart for your desired
cabinet
• Bottom drawer box will be 2 1/4” deep
• Factory installed Roll-out Trays (ROT) are
not
available
PE
APC
APFC
FPEB
MI
DE
RD
ID
l
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
B30
Standard
B30-IF
Inverted Frame
Mullion Strip Wall
MSW
• On double door cabinets (30˝–36˝wide, up
to 42˝ high) the center stile can be removed.
When this is done, a mullion strip is attached
to the left door. Example: W3030-MSW
• Solid wood
• Painted hardwood supplied for EverCore™
• Any wall cabinet over 24˝ wide or 30˝ high or
higher with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
•
Not
available on Peninsula cabinets
•
Not
available with butt door cabinets
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Mullion Strip Base–Void Center Stile
MSB
• On double door cabinets (30” or wider) the
center stile can be removed. When this is
done, a mullion strip is attached to the left
door. Example: B30-MSB.
• Solid wood
• Painted hardwood supplied for EverCore™
•
Not
available with butt door cabinets
•
Note:
This option applies to base cabinets
only
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Mullion Strip Peninsula Base–Void Center Stile
MSPBK
Kitchen Side
MSPBP
Peninsula Side
MSPBB
Both Sides
• On double door cabinets (30˝or wider) the
center stile can be removed. When this is
done, a mullion strip is attached to the left
door. Example: PB30-MSPBK
• Solid wood
• Painted hardwood supplied for EverCore™
•
Not
available with butt door cabinets
•
Note:
This option applies to base peninsula
cabinets only
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
