Specifications and Options
C30
Integrated Extended Stile
Base
BG3 XB
BG3 XR or L
Wall
WG3 XB
WG3 XR or L
• 3˝ integrated extended stiles are available.
Stiles may be extended left, right or both.
Consult option availability chart (XSG) for
your desired cabinet.
• WG3XB is
not
available on wall cabinets that
have a built-in center stile
• Painted hardwood supplied for EverCore™
• Example: B12L-BG3XL. Order designation
G3XL means 3˝ integrated extended stile left,
overall cabinet width 15˝.
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
l
XSG
GD
RTK
RTKP
VTK
Fluted Integrated Extended Stile
Base
FBG3 XB
FBG3 XR or L
Wall
FWG3 XB
FWG3 XR or L
• 3˝ integrated extended stiles are available.
Stiles may be extended left, right or both.
Consult option availability chart (XSG) for
your desired cabinet.
• FWG3XB is
not
available on wall cabinets
that have a built-in center stile
• Painted hardwood supplied for EverCore™
•
Not
available in Sturbridge Oak; Beale,
Hayward Oak and Manchester supplied plain
sawn
• Example: B12L-FBG3XL. Order designation
G3XL means 3˝ integrated extended stile left,
overall cabinet width 15˝.
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
l
XSG
GD
RTK
RTKP
VTK
Glass Door Inserts
GD
• For complete listing of glass door
specifications, see Decorative Doors and
Inserts section of this book
• Annealed Glass
Glass that has been cooled with precise
control to relieve stress introduced by the
manufacturing process. This annealing
process makes the glass workable, i.e. easier
to cut, machine, etc. Common household
glass is annealed glass. It is NOT safety glass.
• Laminated Safety Glass
When broken, laminated safety glass is held
together by the adhesives that are used in
the manufacturing process. This generally
helps keep large pieces of glass from falling
from the opening. Nevertheless, small pieces
and/or chips may still fall, and the precise size
of pieces of glass that will break is difficult to
identify and describe.
• Tempered Glass
Tempering uses either a thermal or chemical
process to quickly harden the glass, which
compresses its surface. Compressing the
surface increases the amount of tensile stress
that can be endured before breakage occurs.
When it does break, tempered glass generally
breaks into very small pieces.
•
Not
available on cabinets with more than four
doors
•
Note:
Most doors (12” or wider and up to
54” high) can be supplied prepared for glass,
with glass inserts, Mullion glass or Aluminum
Frame doors
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
l
GD
RTK
RTKP
VTK
Classic
Camed
Layered
Textured
Etched
Mullion
Aluminum Frame
Construction Options
