Wall Cabinets
D1
Wall Cabinets
Caution
! Installation of a wall cabinet 30˝ or wider requires additional support,
such as attachment to a soffit, or support from below.
Wall Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
Note
: Standard wall cabinet box depth
is 12˝ unless stated otherwise. Add door
thickness with bumpers for total depth.
Caution
: Installation of a wall cabinet
30˝ or wider requires additional support,
such as attachment to a soffit, or support
from below. Failure to provide additional
support could result in collapse of the
cabinet, serious personal injury, or
property damage. Damage relating to
failure to provide additional support is
not
covered by the limited warranty. See inside
cover for warranty details
Any wall cabinet over 24” wide or 30” high
with a depth greater than 12” and/or butt
doors, in addition to Wine Cabinets and
Plate Racks,
must
be installed between two
cabinets, a cabinet and a wall, or supported
from below.
Material dimensions may vary slightly
based on lumber industry standards.
Specifications subject to change without
notice.
PE Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI Matching Interior
DE Integrated Decorative End
RD Reduced Depth
ID Increased Depth
TWR Top Wide Rail
XS Extended Stile
XSG Integrated Extended Stile
GD Glass Doors
WR 30
12
code
width
height
Wall Single Door 12˝ H
Specify R or L
W1212 R or L
W1512 R or L
W1812 R or L
W2112 R or L
• No shelf
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
l
ID
l
TWR
l
XS
XSG
l
GD
12˝
12˝
Wall Double Door 12˝ H
W2412 BUTT
W2712 (Butt)
W3012
W3012 BUTT
W3312
W3312 BUTT
W3412 BUTT
W3612
W3612 BUTT
I
W3712 BUTT
I
W3912
I
W4212
I
W4312
I
W4512
I
W4812
• No shelf
Remember, a cabinet designated
BUTT or (Butt) has no center stile.
When you see the word BUTT in all
capitals, it
must
be included as part of your
ordering nomenclature, a (Butt) in
parentheses is for your information and isn’t
required on an order form
Any wall cabinet over 24˝ wide or
30˝ high or higher with a depth
greater than 12˝ and/or with butt
doors
must
be installed between two (2)
cabinets, a cabinet and a wall or supported
from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
I
ID
l
TWR
l
XS
XSG
l
GD
12˝
W45-48
12˝
W24-43
12˝
12˝
I
Not
available in Increased Depth (ID)
Gray color coding indicates new product, size or code.
