Wall Top Hinge Cabinet 21” and 23 1/2” H w/Auto-open Kit
21” High
WTHG3021 •AO
WTHG3621 •AO
23 1/2” High
WTHG1524 •AO
WTHG2424 •AO
WTHG3024 •AO
WTHG3624 •AO
• One adjustable shelf
• Pressing lower corners of cabinet door
triggers auto-open. Pressing a button on
activator switch triggers auto close. Doors
can be operated manually if desired
• Multiple units can be synced to open and
close simultaneously with the push of one
button
• Auto-open kit requires 110V power source,
preferably above cabinet
• Permaset bumpers are
not
included on door
• 30–36” wide wall cabinets have wood veneer plywood
shelves
I
Antiquity Glass Insert (ATQ)
not
available on 36˝ wide
cabinet.
I
Prep for Glass (DRS•PREP)
not
available
I
Not
available with Crossroads (CRO), Modern Textured
(MRT) and Moire (MOI) Glass Inserts
I
Not
available with Mullion Glass doors
I
Not
available with Camed Glass doors
• Installation instructions supplied; read thoroughly
•
Note
: Requires field installation
•
Note
: Square doors will be supplied when ordered in
arched door styles
Tip: When mounting a 6” Spice Drawer (SD—)
or Organizer (O—) underneath a 23 1/2” cabinet
next to a 30” high wall cabinet, the overall height
will be 29 1/2”. To correct this, you can place a piece of
Stack Molding (STM8) or a 1/2” filler between the 23 1/2”
cabinet and the 6” cabinet.
Any wall cabinet over 24˝ wide or 30˝ high or
higher with a depth greater than 12˝ and/or
with butt doors
must
be installed between two
(2) cabinets, a cabinet and a wall or supported from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
RD
l
ID
TWR
l
XS
XSG
I
GD
21˝
23 ½˝
12˝
Gray color coding indicates new product, size or code.
Wall Refrigerator Top Hinge 24” Deep 21” & 23 1/2” H
21” High
WRTHG3021
WRTHG3621
23 1/2” High
WRTHG3024
WRTHG3624
• One adjustable shelf
• Adjustable Soft-Close lift mechanism
standard
• 30–36” wide wall cabinets have wood veneer
plywood shelves
I
Antiquity Glass Insert (ATQ)
not
available on
36˝ wide cabinet.
I
Prep for Glass (DRS•PREP)
not
available
I
Not
available with Crossroads (CRO),
Modern Textured (MRT) and Moire (MOI)
Glass Inserts
I
Not
available with Mullion Glass doors
I
Not
available with Camed Glass doors
I
Minimum Reduced Depth (RD) is 12˝
•
Note
: Square doors will be supplied when ordered in
arched door styles
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
RD
ID
TWR
l
XS
XSG
I
GD
21˝
23 ½˝
24˝
