Specifications and Options
C34
Construction Options
Scoop Top Drawer
STDW
• Reduced height drawer box for top drawer of
base cabinet only
• 4˝ high drawer box reduced to 2 1/4˝ solid
wood
• 7˝ high drawer box reduced to 4˝ solid wood
• 11˝ high drawer box reduced to 7˝ plywood
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
VTK
Recessed Toe Kick
RTKB
Both
RTKL
Left
RTKR
Right
• Most Base, Tall and Vanity cabinets can be
ordered with a recessed toe kick. Consult option
availability chart for desired cabinet
• You
must
specify end or ends to receive
recessed toe kick
• Painted hardwood supplied for EverCore™
• Additional bottom support is recommended
when using RTKB on peninsula cabinets wider
than 27”
• RTK and WR
not
available on same cabinet
except when combining WR_K and RTKP
options
•
Not
available on 93” and 96” high tall cabinets
We recommend Recessed Toe Kicks
(RTKR or RTKL) on base cabinets at
the end of peninsula runs or island
applications.
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
l
RTK
RTKP
VTK
3
B30-RTKL
Recessedtoekick left
B30-RTKR
Recessedtoekickright
3
3
3
B30-RTKB
Recessedtoekickboth
/ ˝
/ ˝
/ ˝
/ ˝
Recessed Toe Kick Peninsula
RTKP
Back
RTKPB
Back and both sides
RTKPL
Back and left side
RTKPR
Back and right side
• Select Base and Office Cabinets may be
ordered with a Recessed Toe Kick on the back
(Peninsula) side. Consult option availability
chart for desired cabinet.
• You
must
specify end or ends to receive
Recessed Toe Kick Peninsula
• Painted hardwood supplied for EverCore™
• Additional bottom support is recommended
when using RTKPB on cabinets wider than 27”
• RTK and WR
not
available on same cabinet
except when combining WR_K and RTKP
options
•
Not
available on cabinets less than 21˝ deep
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
l
RTKP
VTK
RTKP
RTKPB
RTKPL
RTKPR
Void Toe Kick
VTK
• Select Base, Tall, Office, Furniture and Vanity
Cabinets may be ordered without the toe kick
• Allows decorative feet to be used under cabinet
• Decorative feet, casters or legs should support
the cabinet by way of the end panels,
not
the
cabinet floor
• Full overlay door styles are
not
to be placed
directly on the floor
•
Not
available on Passport cabinets
•
Not
available on 93” and 96” high tall cabinets
•
Not
available with Wide Rail (WR) option
•
Not
available on cabinets with a decorative toe
kick
PE
APC
APFC
FPEB
MI
DE
RD
ID
IF
TWR
WR
XS
XSG
GD
RTK
RTKP
l
VTK
