Wall Cabinets
D8
Wall Cabinets
Wall Refrigerator Top Hinge 24” Deep 18” H
WRTHG3018
WRTHG3618
• No shelf
• Adjustable Soft-Close lift mechanism
standard
I
Antiquity Glass Insert (ATQ)
not
available on
36˝ wide cabinet.
I
Prep for Glass (DRS•PREP)
not
available
I
Not
available with Crossroads (CRO),
Modern Textured (MRT) and Moire (MOI)
Glass Inserts
I
Not
available with Mullion Glass doors
I
Not
available with Camed Glass doors
I
Minimum Reduced Depth (RD) is 12˝
•
Note
: Square doors will be supplied when
ordered in arched door styles
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
RD
ID
TWR
l
XS
XSG
I
GD
24˝
18˝
Wall Refrigerator Top Hinge 24” Deep 18” H w/Auto-open Kit
WRTHG3018 •AO
WRTHG3618 •AO
• No shelf
• Pressing lower corners of cabinet door
triggers auto-open. Pressing a button on
activator switch triggers auto close. Doors
can be operated manually if desired
• Multiple units can be synced to open and
close simultaneously with the push of one
button
• Auto-open kit requires 110V power source,
preferably above cabinet
• Permaset bumpers are
not
included on door
I
Antiquity Glass Insert (ATQ)
not
available on
36˝ wide cabinet.
I
Prep for Glass (DRS•PREP)
not
available
I
Not
available with Crossroads (CRO), Modern
Textured (MRT) and Moire (MOI) Glass
Inserts
I
Not
available with Mullion Glass doors
I
Not
available with Camed Glass doors
I
Minimum Reduced Depth (RD) is 12˝
• Installation instructions supplied; read
thoroughly
•
Note
: Requires field installation
•
Note
: Square doors will be supplied when
ordered in arched door styles
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
RD
ID
TWR
l
XS
XSG
I
GD
24˝
18˝
Gray color coding indicates new product, size or code.
Wall Single Door 23 1/2˝ H
Specify R or L
i;
W924 R or L
W1224 R or L
W1524 R or L
W1824 R or L
W2124 R or L
W2424 R or L
• One adjustable shelf
Tip: When mounting a 6” Spice
Drawer (SD—) or Organizer (O—)
underneath a 23 1/2” cabinet next
to a 30” high wall cabinet, the overall height
will be 29 1/2”. To correct this, you can place
a piece of Stack Molding (STM8) or a 1/2”
filler between the 23 1/2” cabinet and the 6”
cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
l
ID
l
TWR
l
XS
XSG
I
GD
12˝
23 ½˝
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be
square. Huntley, Scarbourough and Veranda
doors will have a solid, recessed flat panel.
;
Glass door option
not
available
