Wall Cabinets
D15
Wall Cabinets
Wall Double Door 48˝ and 54˝ H
Three shelves
48” High
i
W2448 BUTT
W2748 (Butt)
W3048
W3048 BUTT
W3348
W3348 BUTT
W3648
W3648 BUTT
Four shelves
54” High
i
W2454 BUTT
W2754 (Butt)
W3054
W3054 BUTT
W3354
W3354 BUTT
W3654
W3654 BUTT
• Available in full overlay door styles only
• Shelves shipped separately
•
Not
available with Mullion Strip Wall (MSW)
I
Not
available with Camed Glass doors
I
Not
available with Mullion Glass doors
I
Modern Frosted (MRT) and Moire (MOI)
Glass Inserts
not
available on 54˝ H cabinets
I
Maximum Increased Depth (ID) is 15˝
Any wall cabinet over 24˝ wide or
30˝ high or higher with a depth
greater than 12˝ and/or with butt
doors
must
be installed between two (2)
cabinets, a cabinet and a wall or supported
from below
When using 48”–54” high cabinets
or tall stacked cabinet combinations,
remember to supply the best height
Tall End Panel [TEP] for your design needs.
Both 108” and 120” panels can be field cut to
height requirements of your design
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
I
ID
TWR
l
XS
l
XSG
I
GD
48˝
54˝
12˝
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be
square. Huntley, Scarbourough and Veranda
doors will have a solid, recessed flat panel.
Wall Stack Cabinet 48”, 51” and 54” H
Two shelves
48” High
i;
WST948 R or L
WST1248 R or L
WST1548 R or L
WST1848 R or L
WST2148 R or L
WST2448 R or L
WST2448 BUTT
WST2748 (Butt)
WST3048
WST3048 BUTT
WST3348
WST3348 BUTT
WST3648
WST3648 BUTT
Two shelves
51” High
i;
WST951 R or L
WST1251 R or L
WST1551 R or L
WST1851 R or L
WST2151 R or L
WST2451 R or L
WST2451 BUTT
WST2751 (Butt)
WST3051
WST3051 BUTT
WST3351
WST3351 BUTT
WST3651
WST3651 BUTT
Three shelves
54” High
i;
WST954 R or L
WST1254 R or L
WST1554 R or L
WST1854 R or L
WST2154 R or L
WST2454 R or L
WST2454 BUTT
WST2754 (Butt)
WST3054
WST3054 BUTT
WST3354
WST3354 BUTT
WST3654
WST3654 BUTT
• Available in full overlay door styles only
• Two vertical compartments with fixed rail
and floor
• Bottom door is always square
• Shelves shipped separately
•
Not
available with Mullion Strip Wall (MSW)
I
Glass doors available for top doors only
I
To get glass on bottom door, order
appropriate replacement door with glass
option
I
Maximum Increased Depth (ID) is 15˝
Any wall cabinet over 24˝ wide or
30˝ high or higher with a depth
greater than 12˝ and/or with butt
doors
must
be installed between two (2)
cabinets, a cabinet and a wall or supported
from below
When using 48”–54” high cabinets
or tall stacked cabinet combinations,
remember to supply the best height
Tall End Panel [TEP] for your design needs.
Both 108” and 120” panels can be field cut to
height requirements of your design
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
I
ID
TWR
l
XS
l
XSG
I
GD
48˝
51˝
54˝
30˝
33˝
36˝
12˝
18˝
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be
square. Huntley, Scarbourough and Veranda
doors will have a solid, recessed flat panel.
;
Glass door option
not
available
Gray color coding indicates new product, size or code.
