Wall Cabinets
D23
Wall Corner Cabinets
Wall Blind Corner Double Panel 54˝ H
i
WBCDP2454 R or L
WBCDP2754 R or L
WBCDP3054 R or L
WBCDP3354 R or L
WBCDP3654 R or L
WBCDP3954 R or L
• Four adjustable shelves
• Shelves shipped separately
• Available in full overlay door styles only
•
Not
available in mitered door styles
•
Not
available in slab door styles
• Overlay Panel for Wall Blind Corner
Cabinet (OPWBC) is recommended
for full overlay door styles and
must
be
ordered separately; see Base Accessories
Section of this book
I
Maximum Increased Depth (ID) is 15˝
I
Glass doors available for top section only
I
A solid raised center panel machined
to match the veneer raised center panel will be
supplied when glass doors are selected on full
overlay veneer raised panel door styles.
I
Not
available with Mullion Glass doors
Any wall cabinet over 24˝ wide or 30˝ high
or higher with a depth greater than 12˝
and/or with butt doors
must
be installed
between two (2) cabinets, a cabinet and a wall or
supported from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
RD
I
ID
TWR
l
XS
l
XSG
I
GD
54˝
12˝
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be
square. Huntley, Scarbourough and Veranda
doors will have a solid, recessed flat panel.
Flush Finished Blind
FFB
• Wall Blind Corner Cabinets (WBC) are
available with Flush Finished Blind.
Specify FFB.
• Flush finished panel is solid wood
• Painted hardwood supplied for EverCore™
• Example: WBC 2430L-FFB
PE
APC
APFC
FPEB
MI
DE
RD
ID
TWR
XS
XSG
GD
12˝
Peninsula Wall Blind Corner
Specify R or L for Blind
One shelf
23 1/2” High
i
PWBC2724 R or L
i
PWBC3024 R or L
PWBC3324 R or L
PWBC3624 R or L
Two shelves
30” High
Is;
PWBC2430 R or L
i
PWBC2730 R or L
i
PWBC3030 R or L
PWBC3330 R or L
PWBC3630 R or L
33” High
Is;
PWBC2433 R or L
i
PWBC3033 R or L
PWBC3633 R or L
Three shelves
36” High
Is;
PWBC2436 R or L
i
PWBC3036 R or L
PWBC3636 R or L
39” High
Is;
PWBC2439 R or L
PWBC3039 R or L
PWBC3639 R or L
42” High
Is;
PWBC2442 R or L
i
PWBC3042 R or L
PWBC3642 R or L
• R or L indicates blind
• Left shown
• Adjustable shelves
• Frame backs are
not
finished
• See Wall Blind Corner (WBC) cabinet
chart for cabinet specifications
•
Note
: Two 3˝ fillers included. Overlay
Panel for Wall Blind Corner Cabinets
(OPWBC)
must
be ordered separately; see
Wall Accessories section of this book
We recommend using Under
Cabinet Panels (UCP) on all wall
cabinet runs. This will give the
kitchen an elegant finished look. Unless
ordered with a matching wood veneer
interior option, the under side of wall
cabinets are a natural birch material.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
l
RD
l
ID
TWR
l
XS
XSG
I
GD
23
1
/
2
˝
30˝
33˝
36˝
39˝
42˝
12˝
8˝
i
Butt doors on peninsula side
s
Kitchen side door is square except full overlay arched
door styles. Laminate door styles are always square.
Huntley, Scarbourough and Veranda doors will have
a solid, recessed flat panel.
;
Glass door option
not
available
Gray color coding indicates new product, size or code.
