Wall Cabinets
D30
Wall Corner Cabinets
Wall Angle Appliance Garage
Two adjustable shelves
48” High
WAAG2448 R or L
I
WAAG2748 R or L
Three adjustable shelves
54” High
WAAG2454 R or L
I
WAAG2754 R or L
57” High
WAAG2457 R or L
I
WAAG2757 R or L
60” High
WAAG2460 R or L
I
WAAG2760 R or L
• Clearance from countertop to bottom of
door is 20 1/32˝
• Adjustable Soft-Close lift mechanism
standard
• Shelves shipped separately
• Bottom door is always square
• Void All Door and Drawer Front option
(VDA) is
not
available
I
Glass doors available for top doors only
•
Note
: Full overlay door styles use a 1/2”
overlay hinge
I
PE
l
APC
l
APFC
I
FPEB
l
MI
DE
RD
ID
TWR
XS
XSG
I
GD
48˝
54˝
57˝
60˝
12˝, 15˝
Side view
Lift mechanism
Front view
1 / ˝
8 / ˝,
11 / ˝
12 / ˝
10 / ˝
16 / ˝
I
Furniture plywood ends (FPEB) standard
Wall Angle Appliance Garage Lazy Susan
Two shelves
48” High
WAAG2448 R or L•LS
Three shelves
54” High
WAAG2454 R or L•LS
57” High
WAAG2457 R or L•LS
60” High
WAAG2460 R or L•LS
• 19 1/2” diameter rotating shelves
• Clearance from countertop to bottom of
door is 20 1/32˝
• Adjustable Soft-Close lift mechanism
standard
• Bottom door is always square
• Void All Door and Drawer Front option
(VDA) is
not
available
I
Glass doors available for top doors only
•
Note
: Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
RD
ID
TWR
XS
XSG
I
GD
12˝
Front view
1 / ˝
12 / ˝
16 / ˝
48˝
54˝
57˝
60˝
Side view
Lift mechanism
10 / ˝
8 / ˝
Wall Angle Appliance Garage Wood Lazy Susan
Two shelves
48” High
WAAG2448 R or L•WLS
Three shelves
54” High
WAAG2454 R or L•WLS
57” High
WAAG2457 R or L•WLS
60” High
WAAG2460 R or L•WLS
• 19 1/2” diameter rotating shelves
• Shelves rotate independently
• Adjustable Soft-Close lift mechanism
standard
• Rotating shelves have plywood floor and
solid wood trim
• Clearance from countertop to bottom of
door is 20 1/32˝
• Bottom door is always square
• Void All Door and Drawer Front option
(VDA) is
not
available
I
Glass doors available for top doors only
•
Note
: Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
RD
ID
TWR
XS
XSG
I
GD
12˝
Front view
1 / ˝
12 / ˝
16 / ˝
48˝
54˝
57˝
60˝
Side view
Lift mechanism
10 / ˝
8 / ˝
