Passport Cabinets
J8
Passport Cabinet Accessories
Passport cabinetry is available in 1/2” overlay door styles only.
Passport Cabinet
Accessories
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
Material dimensions may vary slightly
based on lumber industry standards.
Not
available in Alder Rustic door styles.
Specifications subject to change without
notice.
PE Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI Matching Interior
XS Extended Stile
AWPL 48
32
code
width
height
Passport Sink Collar
ASRB30
ASRB36
• Designed for use with ABSR
• For use with sink or cooktop
• Includes a Touch Up Kit (TUK)
l
PE
l
APC
l
APFC
l
FPEB
MI
l
XS
5 ½˝
24˝
Passport Plumbing Skirt
ABSR30
ABSR36
• Install with back to wall, creates a 12” deep
knee space
• Removable front
• Water lines and drains including P Trap
must
not
be installed any more than 6” from wall
• Be sure to check your local Accessible Design
codes for necessary clearances
• Cabinet Front Only (CFO) option is available
for clearance flexibility
• Includes a Touch Up Kit (TUK)
• Painted hardwood supplied for EverCore™
•
Note
: Adjacent cabinets
must
have skins or
Furniture Plywood Ends (FPEB) applied
l
PE
l
APC
l
APFC
l
FPEB
MI
l
XS
27˝
12˝
Passport Base Filler
ABF3
ABF6
ABF3X3
• 3/4” thick solid wood
• Painted hardwood supplied for EverCore™
• No toe kick
PE
APC
APFC
FPEB
MI
XS
23 ½˝
23 ½˝
Passport Tall Filler
84” High
ATF3•84
ATF6•84
96” High
ATF3•96
ATF6•96
• 3/4” thick solid wood
• Painted hardwood supplied for EverCore™
• No toe kick
PE
APC
APFC
FPEB
MI
XS
75˝
87˝
