Panels-Shelving-Trays
K3
Custom Appliance Panels
Center Rail Cutout
CUTOUT
• Specify cutout width and height
• The cutout position can be customized based
on the distance specified from the left outside
edge and from the top outside edge of the
door onlay panel
• Refer to appliance manufacturer’s
specification to ensure ice/water dispenser
trim will accommodate a 3/4” to 1” thick
panel
• Cutouts will have 3/16” radius corners
•
Not
available in EverCore™ or High-Gloss
Laminate door styles
Custom Appliance Panel-Frame Only
CAPFO
• Available in the following door styles only if
the stiles and rails are the same dimension:
Mandolay Birch, Mandolay Cherry, and
Mandolay Maple. Otherwise Universal Frame
Only panels
must
be used.
• Frame Only panels will
not
be supplied with
applied molding on applicable door styles.
• Outside edge profiles on stiles and rails will
match the selected door style for Frame Only
panels, and the inside edge profiles will have
a 3/32” radius.
• Multiple doors and panels of identical size
may be ordered by listing the quantity needed.
The quantity will default to one if a number is
not
given.
• Stile and rail sizes can be modified
•
Not
available in laminate, mitered or slab door
styles
•
Not
available in EverCore™ or High-Gloss
Laminate door styles
• Backs are finished
Use with wine chillers that have
framed glass doors
Frame
Minimum Width
8”
Maximum Width
30”
Minimum Height
10”
Maximum Height
80”
Top Rail Height
Minimum Width
1 1/2”
Maximum Width
12”
Bottom Rail Height
Minimum Width
1 1/2”
Maximum Width
12”
Left Stile Width
Minimum Width
1 1/2”
Maximum Width
5”
Right Stile Width
Minimum Width
1 1/2”
Maximum Width
5”
