Panels-Shelving-Trays
K4
Custom Appliance Panels
Universal Custom Appliance Panel-Frame Only
UCAPFO
• Universal Frame Only panels have a 3/32” radius on
both inside and outside edges of stiles and rails
• Frame Only panels will
not
be supplied with applied
molding on applicable door styles.
• Multiple doors and panels of identical size may be
ordered by listing the quantity needed. The quantity
will default to one if a number is
not
given.
•
Not
available in EverCore™ or High-Gloss Laminate
door styles
• Stile and rail sizes can be modified
• Laminates are painted hardwood
• Backs are finished
Use with wine chillers that have framed glass
doors
Frame
Minimum Width
8”
Maximum Width
30”
Minimum Height
10”
Maximum Height
80”
Top Rail Height
Minimum Width
1 1/2”
Maximum Width
12”
Bottom Rail Height
Minimum Width
1 1/2”
Maximum Width
12”
Left Stile Width
Minimum Width
1 1/2”
Maximum Width
5”
Right Stile Width
Minimum Width
1 1/2”
Maximum Width
5”
Custom Appliance Panel–Drawer Onlay Panel
CAPDW
• Five-piece grill panels/drawer heads ordered in heights
less than 6 1/8˝ may be supplied as a solid slab onlay
panel. Some five-piece drawer fronts may have a
recessed center panel.
• Drawer front configuration will follow the selected
door style
• Veneer raised panel door styles will be supplied with
a solid wood center panel machined to resemble the
veneer center panel
• “Width” will be referred to as “Length” on your faxed
acknowledgments for CAPDW only
• If unit is installed at an angle, fillers should be used to
avoid interference with adjacent cabinet
•
Not
available in EverCore™ or High-Gloss Laminate
door styles
• Multiple doors and panels of identical size may be
ordered by listing the quantity needed. The quantity
will default to one if a number is
not
given.
• Stiles and rails will be the same size and profile as the
selected door style
• DRPD and CLDF options are available for applicable
door styles only
• Backs are finished
* Max width is 48” when ordered
taller than 20” (Max height is 30“)
** Max width is 60” when ordered
20” and shorter
Onlay Panel
Minimum Width
6”
Maximum Width
48”*, 60”**
Minimum Height
2 1/4”
Maximum Height
30”, 20”
