Dealer Spec Book - page 534

Passport Cabinets
J2 Passport Cabinets
Passport cabinetry is available in 1/2” overlay door styles only.
Passport Base Single Door w/Tray Divider
Specify R or L
AB9 R or L
• Full height door
• One full height tray divider
l PE
l APC
l APFC
l FPEB
l MI
l RD
IF
TWR
l XS
l GD
l RTK
32 ½˝
24˝
Passport Base Pantry Pull-out
ABPP9 • Unit slides on heavy duty full extension
runners with integrated buffer
• Two fixed wood shelves attached to a full
height door
• Pull out Heights:
Top shelf—8 1/4”
Bottom shelf—7 3/4”
l PE
l APC
l APFC
l FPEB
MI
RD
IF
TWR
l XS
GD
l RTK
4 ½˝
inside shelf
width
32 ½˝
24˝
Passport Base w/Full-Width Tray
Specify R or L
ABFH12 R or L•FWT
ABFH15 R or L•FWT
ABFH18 R or L•FWT
ABFH21 R or L•FWT
ABFH24 BUTT•FWT
ABFH27 (Butt)•FWT
• Full height door
• One adjustable shelf
• One adjustable, full width Roll out Tray
(ROT)
• Roll out Trays (ROT) cannot be included
when a Reduced Depth (RD) option of less
than 18” is selected
l PE
l APC
l APFC
l FPEB
l MI
l RD
IF
TWR
l XS
l GD
l RTK
32 ½˝
24˝
Passport Base w/Two Full-Width Trays
Specify R or L
ABFH12 R or L•2FWT
ABFH15 R or L•2FWT
ABFH18 R or L•2FWT
ABFH21 R or L•2FWT
ABFH24 BUTT•2FWT
ABFH27 (Butt)•2FWT
• Full height door
• Two adjustable, full width Roll out Trays
(ROT)
• Roll out Trays (ROT) cannot be included
when a Reduced Depth (RD) option of less
than 18” is selected
l PE
l APC
l APFC
l FPEB
l MI
l RD
IF
TWR
l XS
l GD
l RTK
32 ½˝
24˝
Passport Base Double Door w/Two Trays
ABFH30 •2T
ABFH33 •2T
ABFH36 •2T
ABFH39 •2T
ABFH42 •2T
ABFH45 •2T
ABFH48 •2T
• Full height door
• 3” center stile
• One adjustable shelf
• Two adjustable Roll out Trays (ROT)
• Roll out Trays (ROT) cannot be included
when a Reduced Depth (RD) option of less
than 18” is selected
l PE
l APC
l APFC
l FPEB
l MI
l RD
IF
TWR
l XS
l GD
l RTK
24˝
32 ½˝
