Passport Cabinets
J1
Passport Cabinets
Passport cabinetry is available in 1/2” overlay door styles only.
Passport Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
Material dimensions may vary slightly
based on lumber industry standards.
Not
available in Alder-Rustic door styles.
Specifications subject to change without
notice.
PE Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI Matching Interior
RD Reduced Depth
IF Inverted Frame
TWR Top Wide Rail
XS Extended Stile
GD Glass Doors
RTK Recessed Toe Kick
AU 18 12 84
code
width
depth
height
Passport Series
Oven accessible
from seated
position
Standard 84”
installation
Install cooktops
at any height
Special sink base
conceals plumbing
Raised dishwasher enclosure for
easier loading & unloading
9˝ high, 6˝ deep
toe kick allows
wheelchair access
32 ½˝ cabinet height
Unique tambour
unit for
unimpaired access
Fully lighted
interior option
Recommendations for Maximum Accessibility:
• Order 36˝ high wall cabinets installed at 82˝ or 84˝ height
• Minimize use of Base cabinets with doors, select drawer or tambour cabinets
Door Style Availability:
• Passport SKU’s are available in all 1/2˝ overlay door styles and are now available with your choice ofWhisper Touch™ or knife hinges (see
door style availability below). Whisper Touch™ hinge features an integrated mechanism that closes doors softly and quietly and is
adjustable six ways for perfect alignment. Knife hinge, which open 180 degrees, are recommended to accommodate wheelchair users.
•
1/2”overlay door styles withWhisper Touch™ hinge:
•
1/2”overlay door styles with knife hinge:
Belmont Roman
Hanley Roman
Belmont Roman
Belmont Square
Hanley Square
Belmont Square
Fox Chase Roman–Half
Harper Cherry
Grandview Cherry Roman–Half
Fox Chase Square–Half
Lyndale–Half
Grandview Cherry Square–Half
Grandview Roman–Half
Marquette Roman–Half
Hanley Roman
Grandview Square–Half
Marquette Square–Half
Hanley Square
Design Recommendations:
• Consider specifying Under Cabinet Panels for wall cabinets available for wheelchair users
