Small Block Chevy 23° Forged Small Block Chevy 23°
MaX Series Flat Top Piston Kits Hollow Dome Pistons
Max Series, 23° small block 350 Small block Chevy 350 forged 2618 alloy pis-
Chevy kits utilize strutted, high [VUZ JVTIPUL [OL ILULÄ[Z VM OVSSV^ KVTLZ HUK
strength 2618 alloy pistons with low a strutted, high strength design. Piston skirts
friction metric piston rings. Flat top are coated with friction reducing ArmorGlide,
pistons feature ArmorGlide coated while lateral gas ports aid compression sealing.
ZRPY[Z MVY YLK\JLK ZJ\ɉUN HUK SH[LYHS Pistons accept .043", .043" and 3.0mm piston
gas ports for maximum compression rings. Sold in sets of eight, complete with .927" x 2.250" piston pins
sealing. Pistons are sold in sets of and spiral locks.
eight, complete with 1.2mm, 1.2mm Rod “0” Deck Comp. Dome
and 3.0mm metric GFX piston rings, Part No. Bore Stroke Length Height At Height Volume
.927" x 2.250" piston pins and spiral locks. WISK0128B3 4.030" 3.480" 6.000" 9.025" 1.250" 13.5cc
WISK0128B4 4.040" 3.480" 6.000" 9.025" 1.250" 13.5cc
Rod “0” Deck Comp. Dome
Part No. Bore Stroke Length Height At Height Volume WISK0129B3 4.030" 3.480" 6.125" 9.025" 1.125" 13.5cc
WISK0002X3 4.030" 3.480" 6.000" 8.990" 1.250" -5.7cc WISK0129B4 4.040" 3.480" 6.125" 9.025" 1.125" 13.5cc
WISK0002X4 4.040" 3.480" 6.000" 8.990" 1.250" -5.7cc
WISK0002X6 4.060" 3.480" 6.000" 8.990" 1.250" -5.7cc Wrist Pin Retainers
WISK0003X3 4.030" 3.480" 5.700" 8.990" 1.550" -5.7cc WISCS-24
WISK0003X4 4.040" 3.480" 5.700" 8.990" 1.550" -5.7cc Replacement, three-layer spiral locks
Ä[ ZTHSS ISVJR *OL]` KPHTL[LY ^YPZ[
pins. Retainers are .075" thick x 1.010" free OD and sold in pairs.

Woodward Precision Steering Components, known for their unique Weld-In Steering Shaft Stubs
features, are the choice of top professional drivers. For example, Fabricate custom length steering shafts with
interchangeable pinion gear assemblies permit the installation of dif- standard 3/4" OD steel tubing.
ferent steering ratios without having to change either the rack shaft
or the housing. Part No. Description
WOOST201A Weld-In Stub, For .120" Wall x 3/4" OD
WOOST201B Weld-In Stub, For. .065" Wall x 3/4" OD
Steering Universal Joints
Steering universal joints feature billet Steering Wheel Quick Releases
bodies, low friction needle roller bearing, 9LSLHZLZ OH]L WYLJPZPVU SV^ WYVÄSL ¸ZX\HYL¹
heat resistant seals and a solid, one-piece splines with 2" of engaged length to resist
trunnion made of 6150 chrome vanadium. U-joints combine zero unintentional removal. Release cannot eject itself
IHJRSHZO ^P[O L_[YLTLS` SV^ VWLYH[PUN LɈVY[ ILJH\ZL VM [OLPY JSVZL HJJPKLU[HSS` HUK YLX\PYLZ TPUPTHS LɈVY[ [V YLSLHZL P[
tolerances. Can operate smoothly at a 30° angle. Splined ends fea- Steel or aluminum pull ring quick releases meet stringent WOOQRA-1
ture two set screws for positive shaft retention. SFI 42.1 specs. Complete with weld-on adapter, bolts and washers.
Part No. Description Part No. Description
WOOUA100 .750" x .750" Smooth Bore WOOQRA-1 Quick Release With Aluminum Pull Ring
WOOUA102 .735", 36-Spline x .750" Smooth Bore WOOQRS Quick Release With Steel Pull Ring

Small Block Chevy Racing Spark Plug Wire Sets
4HU\MHJ[\YLK \ZPUN OPNO X\HSP[` JVTWVULU[Z ( ZPSPJVUL QHJRL[ PZ JV]LYLK ^P[O ÄILYNSHZZ IYHPKLK ,7+4
PUZ\SH[PVU HUK HU (YHTPK ÄILY JVYL PZ JVH[LK ^P[O JVUK\J[P]L SH[L_ ZWPYHS ^YHWWLK PU Z[HPUSLZZ Z[LLS ;OL
resulting wire has the conduction and performance of a metal core. Ready to install, custom tailored wire
sets are race proven. Small block Chevy wires listed include 90° boots at distributor and spark plug ends.
Part No. Description
WDYS813 SB Chevy, HEI, Around Front
WDYS817 SB Chevy, HEI, Around Back
