Page 437 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Aluminum Adapter Fittings
Known for their rapid response to the specialized needs of racers, XRP, Inc. has formed a close working relationship with many professional
HUK HTH[L\Y [LHTZ PU HSS MVYTZ VM TV[VYZWVY[Z ?97»Z X\HSP[` Ä[[PUNZ HYL [OL YLZ\S[ VM [OPZ YLSH[PVUZOPW
Blue Black AN AN Thread
Part No. Part No. Size Part No. Size Size
Male Flare Union Bulkhead Nut
XRP981503 — -3 XRP992403 -3 3/8"-24
XRP981504 XRP981504BB -4 XRP992404 -4 7/16"-20
XRP981506 XRP981506BB -6 XRP992406 -6 9/16"-18
XRP981508 XRP981508BB -8 XRP992408 -8 3/4"-16
XRP981510 XRP981510BB -10 XRP992410 -10 7/8"-14
XRP981512 XRP981512BB -12 XRP992412 -12 1-1/16"-12
XRP981516 — -16 AN
XRP981520 — -20 Part No. Size
Flare Bulkhead
AN
Part No. Size XRP983204 -4
Flare Reducer XRP983206 -6
XRP991902 -4 -3 XRP983208 -8
XRP991905 -6 -3 XRP983210 -10
XRP991906 -6 -4 XRP983212 -12
XRP991908 -8 -4 XRP983216 -16
XRP991912 -8 -6 90° Flare Bulkhead
XRP991914 -10 -6 XRP983303 -3
XRP991915 -10 -8 XRP983306 -6
XRP991919 -12 -8 XRP983308 -8
XRP991920 -12 -10 XRP983310 -10
XRP991923 -16 -12 XRP983312 -12
XRP991926 -20 -16 Flare Bulkhead Tee
XRP983403 -3
Tube Nut Tube Sleeve AN XRP983406 -6
Part No. Part No. Size 45° Flare Bulkhead
Tube Nuts And Tube Sleeve XRP983703 -3
-3 XRP983706 -6
XRP981803-6 XRP981903-6
(6-Pk.) XRP983708 -8
-4
XRP981804-6 XRP981904-6 XRP983710 -10
(6-Pk.) Flare Bulkhead Tee On Run
-6
XRP981806-2 XRP981906-2 XRP980403 -3
(2-Pk.) XRP980404 -4
XRP981808 XRP981908 -8 XRP980406 -6
XRP981810 XRP981910 -10 XRP980410 -10
AN Blue Black AN
Part No. Size Part No. Part No. Size
90° Flare Union 37° Flare Cap Female
XRP982103 -3 XRP992903 XRP992903BB -3
XRP982104 -4 XRP992904 XRP992904BB -4
XRP982106 -6 XRP992906 XRP992906BB -6
XRP982108 -8 XRP992908 XRP992908BB -8
XRP982110 -10 XRP992910 XRP992910BB -10
XRP982112 -12 XRP992912 XRP992912BB -12
Flared Tee XRP992916 — -16
XRP982403 -3 AN AN
XRP982404 -4 Part No. Size Size
XRP982406 -6 Female To Male Flare Seal Expanders
XRP982408 -8 XRP995104 † -3 -4
XRP982410 -10 XRP995106 -4 -6
XRP995108 -6 -8
Pipe AN XRP995110 -8 -10
Part No. Size Size XRP995112 -10 -12
Male Branch Tee XRP995116 -12 -16
XRP982503 1/8" -3 Female To Male Flare Seal Reducers
XRP982504 1/8" -4 XRP995004 † -4 -3
XRP982506 1/4" -6 XRP995006 -6 -4
XRP982508 3/8" -8 XRP995008 -8 -6
XRP982510 1/2" -10 XRP995010 -10 -6
Male Run Tee XRP995011 -10 -8
XRP982603 1/8" -3 XRP995012 -12 -8
XRP982606 1/4" -6 XRP995013 -12 -10
XRP982608 3/8" -8 XRP995016 -16 -10
XRP982610 1/2" -10 XRP995017 -16 -12
XRP982612 3/4" -12 XRP995020 -20 -16
Notes: Female side seals internally on flare nose of mating male fitting -
no O-ring necessary. † Steel.

436
