Ring And Pinion Open Tube Breather Assembly WIN2966
Assemblies Provides a
Gear sets fi t popular 10" diameter, vent for open
12-bolt quick change rear ends. Avail- tube rear end
able with or without bearings. assemblies.
Includes O-ring
Part No. Part No.
Ratio Without Bearings With Bearings boss -6AN
4.11 WIN5714 WIN5715 breather fi t-
4.86 WIN5400 WIN5401 ting, breather
adapter plug, O-ring and 16" of poly tubing.
Quick Change Accessories
Part No. Description Semi-Synthetic Lubricant
WIN3053 Bearing Liner
WIN3067 Cable Bracket, Small WIN1730
WIN4043 Cable Bracket, Two Bolt Specifi cally engineered for rear axles,
WIN6115 Sprint Shim Kit, 9 Pcs. semi-synthetic 80-90-140W Hypoid lube has
WIN6744 Cable Bracket, Large moly additives to reduce friction and enhance
WIN7403T O-Ring, 10" Open Tube Side Bell durability. Sold in 1 gallon containers.
WIN7433 O-Ring Seal, 10" Open Tube
WIN7521 Gear Cover Bearings, Pair WIN3067
WIN4043
Thru Bolt Kit WIN5218
Kit contains ten 7/16"-20 x 5-1/2"
thru bolts, washers and lock nuts.
8500 Series 10-Spline
Posi-Lock Nut Assembly Quick Change Gear Poster
WIN6498R WINPOSTER10
Pinion Posi-Lock nut assembly fi ts 10" Full sized (16-1/2" x 20") poster dis-
quick change rear ends. Positive locking plays tooth count, and ring and pinion
O-ring retains the nut and the spacer. ratio data. Ideal for the race shop or
Easy removal, but still stays in place trailer.
when quick change gears are being changed. Available in right hand
thread only.

Magnesium Sprint
Center Gear Covers
Cover No. Bearing No.
Swivel Spline Driveline Conversion Kit WINK6508 WIN7332
WIN3942-05

Gear Cover Accessories
Swivel Spline Conversion Kit
WIN3942-03
Installation kit 7
with gun drilled steel drive shaft.
Part No. Description
Replacement Components
WIN2975 Swivel Spline Coupler 6
WIN2976-32 Swivel Insert 5
WIN4282 Swivel Spline Seal Kit For Drive Shaft 10
WIN7280 Swivel Spline Seal For Lower Shaft Fig. No. Description Part No.
5 Aluminum High Nut and Stud Kit WIN6390AR
WIN6249HT 5 Aluminum High Nuts Only WIN7794AR
5 Aluminum Short High Nut WIN7794ASR
Lower Shafts 5 3/8"-16 Aluminum Short High Nut WIN7794ASBK
Designed for use on 10" full size WIN6678-03 6 Sprint Center Gasket (Heavy Duty) WIN6729HD
quick change rear ends. 6 Sprint Center Gasket, Gear Cover WIN6729
7 O-Ring, H.D. Sprint Cover Bearing Cap WIN7447
Part No. Description 9 Large Inspection Plug WIN5290-01
WIN6249HT Heat Treated Lower Shaft, Standard Coupler 10 Small Inspection Plug WIN6857
WIN6678-03 Heat Treated Lower Shaft, Internal Coupler
