Page 429 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Front Axle Kit Splined Rear Wheel Center
WIN4245-C-Y WIN3784
Comprehensive kit This splined wheel center is 100% CNC
includes lightweight, machined from forged 2024-T3 aluminum. This
2-1/2" Dia. 4130 chrome moly front axle, forged aluminum direct replacement center fits most popular brands of wheels, while ex-
mount hubs, front spindles, steering arms, steering tie rod, rod ends, ceeding the strength of the original center.
jam nuts, hollow king pins, aluminum king pin caps, left front caliper
mount, wheel bearings, seals, O-rings and necessary hardware.
6-Pin Hub Studs WIN5899
Forged Direct Mount Front Hubs Six front hub drive pins. For knock-off hubs.
Winters aluminum direct mount Front
Hubs are forged from 2024-T3 for supe- Birdcages WINSC2575
rior strength. Aluminum hubs are CNC- This state-of-the-art sprint
machined, maintaining precise toleranc- birdcage is designed with strength
es and gold anodized to resist corrosion. in mind but still emphasizes weight
Complete with dust caps, wheel studs, savings. The forged 7075-T6, black
nuts, bearings, races and seals. anodized birdcage comes in pairs with fully
Part No. Description greasable 28mm angular contact bearings,
WIN3980 Front Forged Aluminum Hub Set, For L/W Spindle integral timing level and all hardware.
WIN3980C Front Forged Aluminum Hub set For L/W Spindle, Silver
Part No. Description
WIN3980B Front Forged Aluminum Hub Set, For L/W Spindle, Black WIN8668 Angular Contact Bearing, 28mm, Sold Individually
WIN7291V Double Lip Seal, For Oil WINSC2574 Caliper Mount With Hardware
Track Star 5 Front Hubs Steel Torque Balls With Boot Assembly
WIN3980-5B WIN4605
Lightweight, forged 2024-T3 alumi- Components are also offered separately.
num front hubs are CNC-machined to
Part No. Description
precise tolerances and offer exceptional WIN4064 Torque Ball
durability, while reducingcritical rotating
weight. Left hubs weighs 3.50 pounds, while WIN4267 Retaining Collar Set
right hub weighs 3.30 pounds. Hubs are
sold complete with screw-in dust caps, wheel studs, nuts, bearings, Torque Ball WIN4064
races and seals.
Sprint oversized Torque Ball assemblies are
offered in standard and lightweight versions.
King Pin Components Lightweight assembly is PTFE coated to reduce friction, decrease
Part No. Description WIN6476-02 wear, and resist corrosion.
WIN1109-02A King Pin Cap, Aluminum
WIN6476-02 King Pin, Steel WIN1109-02A
Aluminum Torque Tube And Collar
Front Spindles WIN6661-02
Part No. Description Aluminum 3" Dia. torque tube is 28" long. Includes alumi-
WIN3622 With Straight Steel Snout num collar.
WIN3622-B With Straight Steel Snout, Black
10-10 Couplers
Part No. Description
Trick Spindle Nut Assembly WIN5987 Standard Steel 10-10 Coupler WIN5987
WIN2377 WIN6676 Integral Steel 10-10 Coupler

U-Joint Assembles
Left Front Caliper Mount The latest development in U-Joint tech-
For 10-7/8" Rotor WINSC2810 nology, Hercules billet 7075 aluminum joints
capture the journal and the U-bolts hold it
WIN4950-16
securely. Weighs only 3.8 pounds and is avail-
Steering Arms able in both 16 or 32 spline.
Part No. Description
All Winters sprint steering arms are forged
7075-T6 aluminum. WIN3700 Aluminum U-Joint Assy. For Chevy/Chrysler
WIN3700-2 Steel/Aluminum U-Joint Assy. For Chevy/Chrysler
Part No. Description
Single Right Front Steering Arm, WIN4950-16 Hercules 16 Spline U-Joint
WIN3451
For 3-1/4" Spindles WIN4950-32 Hercules 32 Spline U-Joint
Combo Left Front Steering Arm,
WIN3452
For 3-1/4" Spindles
428
