Page 426 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

PolyMatrix Brake Pads
Wilwood has many types of brake pad compounds designed specifically for racing. It is important to analyze braking requirements and
select the proper pads. Experimentation is often necessary to determine the correct compound for a particular application.

POLYMATRIX “A” COMPOUND POLYMATRIX “Q” COMPOUND
Heat Range: Low to X-High, Torque: X-High Heat Range: Low to Medium, Torque: Medium
“A” compound delivers an immediate cold response with the high- Ceramic-enhanced compound is ideally suited for aluminum ro-
est friction values at all temperatures. Engineered for severe duty tors. Provides smooth engagement, long service life, quick recovery
oval track race applications which require immediate high response and high fade resistance.
at low temperatures.
POLYMATRIX “CM” COMPOUND
POLYMATRIX “B” COMPOUND Heat Range: Medium To High
Heat Range: High, Torque: High
With quick warm-up, high friction and fade free performance at Best compound for titanium rotors. Medium to high friction sin-
high temperatures, “B” is the best choice for sprints on pavement or tered metallic compound with steadily increasing torque curve as
dirt tracks with extreme braking. temperatures increase.
BP-10 (“SMART PADS”) COMPOUND POLYMATRIX “PURPLE” COMPOUND
Heat Range: Medium to High, Torque: Light to Medium Heat Range: Medium To High
A medium to high temp compound, low dust characteristics and Specially designed for sprint applications using aluminum rotors.
the low temperature response of a street pad. Use on dirt track cars Medium friction compound offers good cold response and moderate
with vented iron rotors, club sport and track day racers. friction without damage to anodized or un-anodized rotors.
POLYMATRIX “E” COMPOUND
Heat Range: Medium to High, Torque: Light to Medium POLYMATRIX BP-40
A proven “Million Dollar” winner and the first choice for all types of (“SMART PADS”) COMPOUND
dirt racing. “E” has immediate cold response, with consistent torque Heat Range: Low to High, Torque: Medium
and pedal response through the entire temperature range. “E” has Improved friction compound is well suited to severe duty oval, road
smooth engagement for finesse driving on slick tracks, with plenty of course and off-road applications that require aggressive response
stopping power right from the start. and durability at the highest of temperatures. Pads offer very high
heat fade resistance and long wear rates with iron and steel rotors.
POLYMATRIX “H” COMPOUND
Heat Range: Low to X-High, Torque: High to X-High
Slightly softer initial response than “A” compound with the same
high temperature friction. Severe duty compound has long wear
characteristics and works well on oval track applications. Delivers
smooth, consistent engagement at all temperatures and pedal pres-
sures.

POLYMATRIX BRAKE PAD CHART • AXLE SETS, 4 PADS PER SET

Pad “A” “B” “BP-10” “E” “H” “Q” “CM/Ti” “Purple”
Caliper Type Type Compound Compound Compound Compound Compound Compound Compound Compound BP-40
Billet Dynalite WIL15Q-
Single 6812 WIL15A-10142K WIL15B-9819K WIL150-9764K WIL15E-9820K — 10144K WIL150-14354K WIL150-9766K —
Dynalite 7112 WIL15A-5734K WIL15B-3991K WIL150-8850K WIL15E-6096K WIL15H-8291K WIL15Q-6824K — — —
(Cotter Pin)
Billet Dynapro
Lug Mount 7812 WIL15A-9835K WIL15B-9836K WIL150-9136K WIL15E-9837K — — — — —
Superlite II, III 7320 WIL15A-5735K WIL15B-3992K WIL150-8856K WIL15E-6100K WIL15H-8108K — — — —
Superlite
6 & Forged S/L 7420 WIL15A-5938K WIL15B-5939K WIL150-8854K WIL15E-6084K WIL15H-8114K WIL15Q-6829K — — WIL150-12245K
Billet Dynapro
Narrow Mount 7816 WIL15A-7263K WIL15B-7264K WIL150-8946K WIL15E-7266K — — WIL150-14346K — —
GP320 6211 — — — — WIL15H-8596K — WIL150-14362K — —
PADS

6211 6812 7112 7812 7320 7420 7816
