GP200 Caliper
The GP 200 billet caliper represents the newest lightweight (only .90 pounds) caliper specifically designed for
tight fit applications while utilizing a standard 2.38" lug mount. Combines superior strength with a black anodized
finish along with several new performance features. The strength of the GP 200 is a combination of process and
design. GP 200 calipers are fully CNC machined from premium grade alloy billet. Use 4908 type pads.
Piston Rotor 4-Pc. Sq.
Part No. Diameter Thickness Ring Kit
WIL120-12178 1.23" 0.25" WIL130-3602

GP 320 Calipers
The GP 320 billet four piston caliper is a compact, high efficiency performer. Weighing just 1.70 pounds, it was
purpose built as an upgrade with increased pad size over two piston calipers on lightweight open wheeled race
cars. The GP 320 is also well suited to other performance and racing applications including, but not limited to
karts, motorcycles, mini-sprints, and formula sports racers. The GP 320 bridge configuration will accommodate
rotors between .19" and .25" thick, with overall diameters between 9.00" and 11.50". Use 6211 type pads.
Piston Rotor 4-Pc. Sq.
Part No. Application Diameter Thickness Ring Kit
WIL120-8524 Right Rear 1.25" .235" WIL130-3602
WIL120-8525 Left Rear 1.25" .235" WIL130-3602
Billet Narrow Dynalite Radial Mount DynaPro Inboard Brake System WIL140-11762
Sprint Inboard Brake Kit System is for Sprint quick change rears
WIL140-12764 with 3.00" x 46-spline axles. Includes
10.5" x .810" polymetallic titanium vented
A fully engineered bolt-on brake system rotors (2.37 Lbs. each), dynamic mount
for sprint car quick change rears with 3.00" rotor axle clamps and forged billet Dy-
x 46- splined axles. With titanium, Super naPro radial mount calipers with metallic
Alloy or Steel, .810 vented or solid discs pads. Sold in pairs.
and a newly designed dynamic mount rotor Part No. Description
axle clamp, are the lowest rotating weights
available for Sprint racing. The lightweight Replacement Component
advantages of Wilwood Sprint rotors are fortified with the high du- WIL250-13150 Caliper Bracket
rability, long wear, and superior heat control properties of advanced
materials. Billet Dynalite Radial mount calipers with either composi- GP320 Sprint Brake Kits WIL140-11773 WIL140-11774
tion metallic or BP-40 pads, produce superior stopping power and Brake kit offers sub-
consistent fade-free response. Kit includes axle clamp with dual stantially improved brak-
mount rotor adapter with T-nuts, radial mount bracket assembly and ing and durability when
mounting hardware. compared to traditional
Part No. Description aluminum rotor systems.
Replacement Components GP320 forged billet
WIL120-13405-N Caliper aluminum four piston
WIL270-12633 Hub calipers are rigid, yet
WIL230-10483 Bolt Kit lightweight and deliver
WIL160-12571 Rotor exceptional braking torque, while the polymetallic stainless steel
WIL250-13365 Mount rotors provide superior thermal performance and wear resistance.
Kit is complete with caliper, brake pads, rotor, rotor adapter and
Billet Narrow Dynalite Radial necessary hardware.
Part No. Description
Mount Sprint Inboard Brake Kit WIL140-11773 Front Brake Kit
This kit features a bolt-on brake system WIL140-11774 Right Rear Kit
for sprint car quick change rears with 3.00"
x 46 splined axles, and a dynamic mount
rotor axle clamp, offering low rotating Left Front Brake Kit WIL140-14270
weight. The newly redesigned nickel billet Left Front Sprint & Midget kits are a further
Dynalite radial mount calipers with com- evolution of a proven design from wilwood’s
position metallic pads, produce excellent 35+ years of engineering and producing the
stopping power and a consistent fade-free best open wheel braking systems. Dynapro
response. Kit includes axle clamp with dual single calipers have full 2.40 square inches of
mount rotor adapter with T-nuts, radial area for increased clamping force. Kits are of-
mount bracket assembly and mounting hardware. WIL140-11206 fered with either slotted titanium or scalloped
alloy steel rotors for high heat or aluminum
Part No. Description
WIL140-11206 10.50" x .780" Vented, Super Alloy, Scalloped Drilled Rotor rotors for maximizing weight saving on light braking tracks. Kit come
complete with caliper, brake pads, caliper mounting brackets, caliper
WIL140-13496 11.75" x .810" Vented, Standard Rotor
mount bolt kit, rotor and rotor mounting hardware.
WIL140-15147 11.75" x .810" Vented, Super Alloy, Scalloped Rotor
Part No. Description
Replacement Component
WIL160-14184 Rotor
