194 / 601
D35
Wall Hoods
Wall Cabinets
Peninsula Wall Hood Classic Chimney Flat Panel Valance
Plain
32” High
PWHCCFPV302832 •P
PWHCCFPV363332 •P
PWHCCFPV423332 •P
44” High
PWHCCFPV302844 •P
PWHCCFPV363344 •P
PWHCCFPV423344 •P
56” High
PWHCCFPV302856 •P
PWHCCFPV363356 •P
PWHCCFPV423356 •P
Beaded Panel
32” High
PWHCCFPV302832 •BE
PWHCCFPV363332 •BE
PWHCCFPV423332 •BE
44” High
PWHCCFPV302844 •BE
PWHCCFPV363344 •BE
PWHCCFPV423344 •BE
56” High
PWHCCFPV302856 •BE
PWHCCFPV363356 •BE
PWHCCFPV423356 •BE
• Solid wood/wood veneer
construction
• Check local building codes for
required clearances between the
Wall Hood and cooking surface
• A 3˝ space is recommended
on the right and left side of
this unit before beginning the
adjacent cabinet runs
• 32˝ high hoods are designed for
use with 8 foot ceilings
• 44˝ high hoods are designed for
use with 9 ft. ceilings
• 56˝ high hoods are designed for use with 10
ft. ceilings
• Decorative molding matches Soffit Crown
Molding profile (SCM8)
• Chimney section shipped separately
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™
and Laminate
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
• 30˝ wide requires Wall Hood Component
Package “K”, located before the Wall Hood
Designs in this section
• 36˝–42˝ wide requires Wall Hood
Component Package “H” or “O”, located
before the Wall Hood Designs in this section
•
Note:
Cabinetry and appliances located
below these Wall Hoods
must
be pulled to a
minimum of 27˝deep and a maximum of 30˝
deep for improved function
•
Note:
Wall hood
must
be securely anchored
to ceiling
PE
v
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
PWHCCFPV30
7 ⁄
˝
6 ⁄
˝
28 ⅝˝
24 ½˝
PWHCCFPV36
14 ½˝
10 ½˝
34 ⅝˝
28 ½˝
PWHCCFPV42
20 ½˝
10 ½˝
40 ⅝˝
28 ½˝
PWHCCFPV•P
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
32˝
44˝
56˝
11
15
/
16
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
32˝
44˝
56˝
11
15
/
16
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
PWHCCFPV•BE
Unless indicated, measurements include molding
Wall Hood Classic Artisan Chimney
30 5/8” High
WHCC301930 •A
WHCC361930 •A
WHCC362430 •A
WHCC422430 •A
42 5/8” High
WHCC301942 •A
WHCC361942 •A
WHCC362442 •A
WHCC422442 •A
54 5/8” High
WHCC301954 •A
WHCC361954 •A
WHCC362454 •A
WHCC422454 •A
• Solid wood/wood veneer
construction
• Check local building codes for
required clearances between the
Wall Hood and cooking surface
• Will accept optional onlays,
ordered separately; see Molding
Accents section of this book
• A 3˝ space is recommended
on the right and left side of
this unit before beginning the
adjacent cabinet runs
• 30 5/8˝ high hoods are designed
for use with 8 foot ceilings
• 42 5/8˝ high hoods are designed for use with
9 ft. ceilings
• 54 5/8˝ high hoods are designed for use with
10 ft. ceilings
• Shaded areas are unfinished surfaces that
allow for field application of paint or other
decorative material
• Lower molding matches Beaded Panel
Molding (BPM8) profile, other molding
matches Soffit Crown Molding profile (SCM8)
• This product will
not
be covered under
warranty once alterations of any kind have
been made
• Chimney section shipped separately
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™
and Laminate
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
• 19˝ deep requires Wall Hood Component
Package “J”, located before the Wall Hood
Designs in this section
• 24˝ deep requires Wall Hood Component
Package “G” or “P”, located before the Wall
Hood Designs in this section
•
Note:
Cabinetry and appliances located
below these Wall Hoods
must
be pulled to a
minimum of 27˝deep and a maximum of 30˝
deep for improved function
•
Note:
Wall Hood
must
be securely anchored
to wall
PE
v
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
WHCC30•A
8˝
7 ⁄
˝
28 ½˝
18 ⁄
˝
WHCC36•A
14 ⁄
˝
10 ¾˝
34 ½˝
21 ⁄
˝
WHCC42•A
20 ½˝
10 ¾˝
40 ½˝
21 ⁄
˝
20
3
/
16
˝
23
7
/
16
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
3
/
4
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
6
5
/
16
˝
8˝, 20˝, 32˝
22
5
/
8
˝
30
5
/
8
˝
42
5
/
8
˝
54
5
/
8
˝
WHCC•A
Unless indicated, measurements include molding.
Shaded areas are unfinished.
Select a Wall Hood Classic Artisan Chimney when your design requires a customer
specified finish treatment such as tile, stucco, metal or paint. The chimney and angled
sections of the hood are unfinished to allow paint or other adhesives to hold more
securely. The valance and molding section will match the wood and finish of your chosen door
style.
