196 / 601
D37
Wall Hoods
Wall Cabinets
Peninsula Wall Hood Classic Chimney Raised Panel Valance
Plain
32” High
PWHCCRPV302832 •P
PWHCCRPV363332 •P
PWHCCRPV423332 •P
44” High
PWHCCRPV302844 •P
PWHCCRPV363344 •P
PWHCCRPV423344 •P
56” High
PWHCCRPV302856 •P
PWHCCRPV363356 •P
PWHCCRPV423356 •P
Beaded Panel
32” High
PWHCCRPV302832 •BE
PWHCCRPV363332 •BE
PWHCCRPV423332 •BE
44” High
PWHCCRPV302844 •BE
PWHCCRPV363344 •BE
PWHCCRPV423344 •BE
56” High
PWHCCRPV302856 •BE
PWHCCRPV363356 •BE
PWHCCRPV423356 •BE
• Solid wood/wood veneer
construction
• Check local building codes for
required clearances between the
Wall Hood and cooking surface
• A 3˝ space is recommended
on the right and left side of
this unit before beginning the
adjacent cabinet runs
• 32˝ high hoods are designed for
use with 8 foot ceilings
• Decorative molding matches Soffit Crown
Molding profile (SCM8)
• Chimney section shipped separately
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™
and Laminate
•
Not
available in Woodgrain Laminate door
styles
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
• 30˝ wide requires Wall Hood Component
Package “K”, located before the Wall Hood
Designs in this section
• 36˝–42˝ wide requires Wall Hood
Component Package “H” or “O”, located
before the Wall Hood Designs in this section
•
Note:
Cabinetry and appliances located
below these Wall Hoods
must
be pulled to a
minimum of 27˝deep and a maximum of 30˝
deep for improved function
•
Note:
Wall hood
must
be securely anchored
to ceiling
PE
v
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
PWHCCRPV30
7 ⁄
˝
6 ⁄
˝
28 ⅝˝
24 ½˝
PWHCCRPV36
14 ½˝
10 ½˝
34 ⅝˝
28 ½˝
PWHCCRPV42
20 ½˝
10 ½˝
40 ⅝˝
28 ½˝
WHCCRPV•P
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
32˝
44˝
56˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
15
/
16
˝, 15˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
32˝
44˝
56˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
15
/
16
˝, 15˝
PWHCCRPV•BE
Unless indicated, measurements include molding
Wall Hood Box
18” High
WHB301818
WHB361818
WHB362118
WHB422118
23 1/2” High
WHB301824
WHB361824
WHB362124
WHB422124
30” High
WHB301830
WHB361830
WHB362130
WHB422130
36” High
WHB301836
WHB361836
WHB362136
WHB422136
• Solid wood/wood veneer
construction
• Laminates are painted hardwood
• All door styles will default to full
overlay
• Doors are attached by false front
clips.
Not
operational
• Designed to align with top of
adjacent cabinets
• 30” and 36” wide hoods have a single door
panel
• 42” wide hoods have three door panels
• 19” deep requires Wall Hood Component
Package “J”, located before the Wall Hood
Designs in this section
• 22” deep requires Wall Hood Component
Package “G” or “P”, located before the Wall
Hood Designs in this section
• Check local building codes for required
clearances between the Wall Hood and
cooking surface
• The 18” high Wall Hood Box will require a
soffit or a molding box application to house
the duct work for the blower unit
•
Not
available in Northwood Roman,
Northwood Square, Stratford Roman or
Stratford Square door styles
•
Note:
Square doors will be supplied when
ordered in arched door styles
•
Note:
Cabinetry and appliances located
below these Wall Hoods
must
be pulled to a
minimum of 27˝deep and a maximum of 30˝
deep for improved function
PE
APC
v
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
WHB30-36
18˝
23
1/ ˝
30˝
36˝
18˝
23
1/ ˝
30˝
36˝
19˝, 22˝
30˝, 36˝
42˝
22˝
WHB42
