D32
Wall Hoods
Wall Cabinets
Wall Hoods
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
DE Integrated Decorative End
RD Reduced Depth
ID Increased Depth
XS
Extended Stile
XSG Integrated Extended Stile
GD Glass Doors
Consult your local building code for rules and regulations that may apply to the
installation of this product.
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
WHCC 36 24 30
code
width depth height
Wall Hood Classic
CRHF3024 •BE
CRHF3624 •BE
CRHF3024 •P
CRHF3624 •P
• Solid wood/wood veneer construction
• Metal liner required
• Requires Wall Hood Component Package “B”
or “E”, located before the Wall Hood Designs
in this section
•
Not
available in Alder–Rustic door styles
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
• Painted hardwood supplied for EverCore™
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
•
Note:
Wall Hood
must
be installed between
two cabinets
PE
l
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
7˝
•BE
7˝
23 ½˝
23 ½˝
5¾˝
5¾˝
•P
Peninsula Wall Hood Classic
PCRH3624 •BE
PCRH3624 •P
• Solid wood/wood veneer construction
• Requires Wall Hood Component Package “C”
or “F”, located before the Wall Hood Designs
in this section
•
Not
available in Alder–Rustic door styles
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
• Painted hardwood supplied for EverCore™
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
•
Note:
Wall hood
must
be securely anchored to
ceiling or soffit
PE
l
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
Wall Hood Matching
Ogee Molding
RH3024 •OG
RH3624 •OG
• Solid wood/wood veneer construction
• Metal liner required
• Doors open to facilitate duct installation and
wiring
• Requires Wall Hood Component Package “A”
or “D”, located before the Wall Hood Designs
in this section
•
Not
available in Alder–Rustic door styles
•
Not
available in High-Gloss Laminate or
Woodgrain Laminate door styles
• Painted hardwood supplied for EverCore™
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
•
Note:
Wall Hood
must
be installed between
two cabinets
PE
l
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
open
RH•OG
12˝
23
1
/
2
˝
21
1
/
2
˝
5
1
/
4
˝
