190 / 601
D31
Wall Microwave Cabinets
Wall Cabinets
Wall Microwave Box
18” High
Opening trimmable to:
Width: 16” to 25” Height: 11” to 15 1/2”
WMB271818
WMB272118
Opening trimmable to:
Width: 19” to 28” Height: 11” to 15 1/2”
WMB301818
WMB302118
21” High
Opening trimmable to:
Width: 16” to 25” Height: 14” to 18 1/2”
WMB271821
WMB272121
WMB272421
Opening trimmable to:
Width: 19” to 28” Height: 14” to 18 1/2”
WMB301821
WMB302121
WMB302421
23 1/2” High
Opening trimmable to:
Width: 16” to 25” Height: 17” to 21 1/2”
WMB272124
WMB272424
Opening trimmable to:
Width: 19” to 28” Height: 17” to 21 1/2”
WMB302124
WMB302424
• Designed for “built-in” style microwaves
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Back Options (BEB and VGRB)
not
available
• Painted hardwood supplied for EverCore™
•
Note: Must
be installed between two
cabinets or cabinet and wall with supplied
connectors
l
PE
l
APC
l
APFC
l
FPEB
MI
l
RD
ID
XS
GD
18˝
21˝
18˝, 21˝,24˝
23½˝
Wall Microwave Shelf
15” High
Inside Dimensions:
WMS211515
19 3/8” x 12 11/16”
WMS241515
22 3/8” x 12 11/16”
WMS211815
19 3/8” x 12 11/16”
WMS241815
22 3/8” x 12 11/16”
18” High
WMS241818
22 3/8” x 15 11/16”
WMS271818
25 3/8” x 15 11/16”
WMS301818
28 3/8” x 15 11/16”
WMS242118
22 3/8” x 15 11/16”
WMS272118
25 3/8” x 15 11/16”
WMS302118
28 3/8” x 15 11/16”
21” High
WMS241821
22 3/8” x 18 11/16”
WMS271821
25 3/8” x 18 11/16”
WMS301821
28 3/8” x 18 11/16”
WMS242121
22 3/8” x 18 11/16”
WMS272121
25 3/8” x 18 11/16”
WMS302121
28 3/8” x 18 11/16”
• 3/4˝ wood veneer construction
• Designed for countertop style microwaves
• Painted hardwood supplied for EverCore™
•
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
•
Note: Must
be installed between two cabinets
or cabinet and wall with supplied connectors
Do
not
design a wall hood or
microwave shelf adjacent to a corner
cabinet. The door of the corner
cabinet will
not
function.
PE
l
APC
APFC
FPEB
v
MI
RD
ID
XS
GD
12˝
15˝
18˝
21˝
15˝, 18˝, 21˝
