187 / 601
D28
Wall Microwave Cabinets
Wall Cabinets
Wall Microwave
Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
Installation Notes: Installation of a wall cabinet 30” or wider, by itself, is
not
recommended by KraftMaid® and requires additional support, such as attachment
to a soffit, or support from below.
Any wall cabinet over 24” wide or 30” high with a depth greater than 12” or butt doors
must
be installed between two cabinets, a
cabinet and a wall, or supported from below.
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
WMC 30 18 36
code
width depth height
Wall Microwave Cabinet
36” High
Opening trimmable to:
Width: 16” to 25” Height: 13” to 19”
WMC271836 (Butt)
WMC272136 (Butt)
WMC272436 (Butt)
Opening trimmable to:
Width: 19” to 28” Height: 13” to 19”
WMC301836
WMC302136
WMC302436
45” High
Opening trimmable to:
Width: 16” to 25” Height: 13 1/2” to 19 1/2”
WMC271845 (Butt)
WMC272145 (Butt)
WMC272445 (Butt)
Opening trimmable to:
Width: 19” to 28” Height: 13 1/2” to 19 1/2”
WMC301845
WMC302145
WMC302445
• Designed for “built-in” style microwaves
•
Note: Must
be installed between two
cabinets or cabinet and wall with supplied
connectors
Installation of a wall cabinet 30” or
wider, by itself, is
not
recommended by KraftMaid® and
requires additional support, such as
attachment to a soffit or support from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
ID
l
XS
l
GD
15˝
21˝
36˝
18˝, 21˝, 24˝
WMC_36
WMC_45
24˝
21˝
45˝
18˝, 21˝, 24˝
Wall Microwave Cabinet–Extended Opening
36” High
Opening trimmable to:
Width: 16” to 25” Height: 16” to 22”
WMCE272136 (Butt)
WMCE272436 (Butt)
Opening trimmable to:
Width: 19” to 28” Height: 16” to 22”
WMCE302136
WMCE302436
45” High
Opening trimmable to:
Width: 16” to 25” Height: 16 1/2” to 22 1/2”
WMCE272145 (Butt)
WMCE272445 (Butt)
Opening trimmable to:
Width: 19” to 28” Height: 16 1/2” to 22 1/2”
WMCE302145
WMCE302445
• Designed for “built-in” style microwaves
•
Note: Must
be installed between two
cabinets or cabinet and wall with supplied
connectors
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
ID
l
XS
l
GD
12˝
24˝
36˝
21˝, 24˝
WMCE_36
WMCE_45
21˝
24˝
45˝
21˝, 24˝
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
RD Reduced Depth
ID Increased Depth
XS
Extended Stile
GD Glass Doors
