E24
Base Specialty Cabinets
Base Cabinets
Base Specialty
Cabinets
Construction Options and
Modifications
I
Available with exceptions
l
Available with an upcharge
v
Included as standard
(Blank)
Not
available
Material dimensions may vary slightly
based on lumber industry standards.
Specifications subject to change
without notice.
PE Plywood Ends
APC All Plywood Construction
BWBT 18 •2
code
width
suffix
Base Filler Pull-Out
BFP3
2 3/4” shelf width; 1 3/4” usable space
between chrome rails; 3 1/16” required
between adjacent cabinets
BFP6
5 3/4” shelf width; 4 3/4” usable space
between chrome rails; 6 1/16” required
between adjacent cabinets
• 3/4” thick solid wood pre-drilled filler
included, shipped unattached
• Wood filler aligns with face frames of adjacent
wall cabinets
• Three adjustable hardwood shelves
• Full extension runners; one on top, two on
bottom
• Must be installed between two base cabinets
• Natural finish hardwood interior
Do
not
use filler pullouts at the end
of cabinet runs or next to
appliances. They
must
be installed
between two cabinets or a cabinet and an end
panel
PE
APC
3˝, 6˝
29 / ˝
34½˝
Base Pantry Pull-Out
BPP9
• Four-tier (three adjustable fixed shelves)
maple base organizer with clear coat finish
• Full-height door attached to pull-out
• Tiers are 3 3/4” wide
• 1/4” diameter chrome plated steel rail side
extensions help prevent stored items from
falling out, yet still viewable
• White epoxy coated full-extension ball bearing
slides
l
PE
l
APC
34 ½˝
24˝
Base Top Mount Wastebasket – Single
BWBT15
• One standard height full-width drawer
• Includes one 35 qt. white plastic basket and
one 5 1/2” deep white plastic tray for garbage
bag storage
• Basket is easily removable for emptying or
cleaning
• Top mounted wastebasket assembly rolls out
on full-extension ball-bearing slides
l
PE
l
APC
34 ½˝
24˝
