3˝
3˝
34 ½˝
24 / ˝
Sink
PBBC
PB
Kitchen Side
Peninsula Side
Blind panel
w/3” filler
24 / ˝
3” Filler
w/toekick
backer
Kitchen Side
Peninsula Side
E20
Base Corner Cabinets
Base Cabinets
Peninsula Base Blind Corner Double Door
PBBC27 BUTT
• One adjustable shelf
• Cabinet is 24” wide
• Cabinet can be pulled a maximum of 3”
from wall
• Working drawer and door(s) on peninsula
side
• Use to start a peninsula run
• One 3” filler (BF3) and toespace assembly
(toekick backer) included, shipped
unattached
• Blind Panel with 3” filler included, shipped
unattached
• Front and back face frames are pre-drilled for
optional roll out trays
l
PE
l
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
l
1FWROT
l
2FWROT
2DROT
l
2DFWROT
CFO
Peninsula Base Blind Corner w/Two Full-Width Trays
Specify R or L
PBBC27 R or L•2FWT
PBBC27 BUTT•2FWT
• Cabinet is 24” wide
• Cabinet can be pulled a maximum of 3”
from wall
• Working drawer and door(s) on peninsula
side
• Use to start a peninsula run
• One 3” filler (BF3) and toespace assembly
(toekick backer) included, shipped
unattached
• Blind Panel with 3” filler included, shipped
unattached
• Two standard Full-width Roll-out Trays
(FWROT)
• Front and back face frames are pre-drilled for
optional roll out trays
l
PE
l
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
1FWROT
2FWROT
2DROT
2DFWROT
CFO
3˝
3˝
34 ½˝
24 / ˝
Kitchen Side
Peninsula Side
Peninsula Base Blind Corner w/Two Deep Full-Width Trays
Specify R or L
PBBC27 R or L•2DFWT
PBBC27 BUTT•2DFWT
• Cabinet is 24” wide
• Cabinet can be pulled a maximum of 3”
from wall
• Working drawer and door(s) on peninsula
side
• Use to start a peninsula run
• One 3” filler (BF3) and toespace assembly
(toekick backer) included, shipped
unattached
• Blind Panel with 3” filler included, shipped
unattached
• Two Deep Full-width Roll-out Trays
(DFWROT)
• Front and back face frames are pre-drilled for
optional roll out trays
l
PE
l
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
1FWROT
2FWROT
2DROT
2DFWROT
CFO
3˝
3˝
34 ½˝
24 / ˝
Kitchen Side
Peninsula Side
