E15
Base Cabinets
Base Cabinets
Removable Sink Front
One Drawer Front
RSF30 BUTT
RSF33 BUTT
RSF36 BUTT
Two Drawer Fronts
RSF42
• Designed for easy field conversion from
a standard sink base functionality to
universal access open space
• Permanently installed countertop support
rail is 6-1/2” high x 3/4” thick solid wood
with a factory installed standard height
matching false drawer front(s) providing
a seamless sink base appearance. (1) full-
width drawer front on 30”, 33” and 36”
widths; (2) false drawer fronts on 42” wide
• If a shorter countertop support is
required when used for universal access as
additional vertical clearance, a 3” filler can
be used in place of the 6 1/2” high support
rail. Order separately
• 3/4” thick removable plywood bottom
panel with support hardware / leveling
legs and a removable clipped-on toeboard
provided
• Matching solid wood baseboard provided for
bottom panel support along the kitchen wall
• Frame, doors, floor bottom and toeboard can
be flat packed for easy storage in a minimum
amount of space
• Frame attached to bottom panel using quick
connect (cam-locks) fasteners providing a
solid tight joint
• Some field assembly required; instructions and
hardware included
• A Universal Access Panel (UAP) can be
purchased separately to conceal/protect the
water and drain lines. See “Panels” section.
Please specify specie and finish
• Doors and frame are shipped pre-assembled
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
CFO
34 ½˝
24˝
Universal Access Panel
UAP30
UAP33
UAP36
UAP42
• Designed for optional use with Removable
Sink Front (RSF) and Universal Removable
Sink Front (URSF)
• Conceals/protects drain and water lines
• Includes one 9” and one 15” high, 3/4”
thick laminate plywood panel
• Panels are held with hidden spring clips,
removable without tools for easy access to
plumbing
• Must be trimmed when Wood Veneer
Paneling (WSK) is used on adjacent
cabinets
• Installation instructions and mounting
hardware included
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
CFO
